No. 049 Wardrobe
Stock number: 80312403
Thank you for purchasing this No 049 Wardrobe. Please read the instructions carefully before use to ensure safe
and satisfactory operation of this product.
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Necessary Tools
Please check the pack contents before attempting to assemble this product. A full checklist of components
is given in this leaflet. If any components are missing, please contact John Lewis Customer Services or
your local branch.
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE
WHEN LIFTING to avoid personal injury or damage to the product.
This product takes approximately 60 MINUTES to assemble with 2 PEOPLE
The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG
CHILDREN.
Read this leaflet in full before commencing assembly.
1
Advertisement
Related Manuals for John Lewis 049
Summary of Contents for John Lewis 049
- Page 1 No. 049 Wardrobe Stock number: 80312403 Thank you for purchasing this No 049 Wardrobe. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Pre-assembly preparation Please ensure instructions are read in full before attempting to assemble this product Necessary Tools Please check the pack contents before attempting to assemble this product.
- Page 2 Fittings and parts checklist 8x Spring Top Panel Washer 8x Flat 2x Side Panel Washer 6x Cam Base Panel Bolt 6x Cam 2x Doors Head 12x30mm Shelf Screws 24x20mm Back Panel Screws 2x Hanging Rail Hex Key Drawer box Wall Strap 2x20mm 4x Legs Screws...
- Page 3 Step by step assembly instructions Step One On a soft, clean and level surface insert 6x cam bolts (N) into the Side Panels (B). Step Two With the aid of an assistant attach the Shelf Panel (E) to the Side Panels (B) as shown below using 6x Cam heads (O).
- Page 4 Step Three With the aid of an assistant attach the Base panel (C) by inserting the wood screws (P) into the pilot holes provided. Step Four With the aid of an assistant attach the Top Panel (A) by inserting the wood screws (P) into the pilot holes provided.
- Page 5 Step Five Fit the back panel onto the reverse of the wardrobe by inserting the wood screws (Q) into the pilot holes provided. Step Six Attach the Legs (I) to the Base panel (C) using the bolts (K) provided. Ensure that the flat washers (M) rest against the timber leg trapping the spring washer (L) inbetween the flat washers (E) and the head of the bolt.
- Page 6 Step Seven With the aid of an assistant carefully lift the wardrobe onto its feet. Install the Hanging Rails (G). Step Eight Attach hinges (U) by inserting the screws (V) into the pilot holes provided.
- Page 7 Step Eight With the aid of an assistant carefully present the doors (D) onto the frame and attach hinges (U) to the side panel. Once the wardrobe is placed into its final position the doors can be aligned by following the instructions in the diagrams below. Step Nine Insert the Metal Hanging Rails (J) into the back of the doors (D).
- Page 8 Your wardrobe is supplied with wall fixing straps which John Lewis would recommend is used to Step Ten secure the product to the wall. Attach one end of the wall fixing strap to the top of the unit with the screw provided and the other end should be attached to the wall by a competent person using a fixing suitable for your wall.
-
Page 9: Care And Maintenance
Care and Maintenance The John Lewis No 049 bedroom collection is crafted from solid Oak and Oak veneers and then finished with a light lime wash and lacquer. The woods and veneers used in this furniture have been specially selected for their natural beauty and characteristic appearance.
