No. 049 Mirror
Stock number: 80312412
Thank you for purchasing this No 049 Mirror. Please read the instructions carefully before use to ensure safe and
satisfactory operation of this product.
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Necessary Tools
Please check the pack contents before attempting to assemble this product. A full checklist of components
is given in this leaflet. If any components are missing, please contact John Lewis Customer Services or
your local branch.
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE
WHEN LIFTING to avoid personal injury or damage to the product.
This product takes approximately 45 MINUTES to assemble with 2 PEOPLE
The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG
CHILDREN.
Read this leaflet in full before commencing assembly.
1
Advertisement
Related Manuals for John Lewis 049
Summary of Contents for John Lewis 049
- Page 1 No. 049 Mirror Stock number: 80312412 Thank you for purchasing this No 049 Mirror. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Pre-assembly preparation Please ensure instructions are read in full before attempting to assemble this product Necessary Tools Please check the pack contents before attempting to assemble this product.
- Page 2 Fittings and parts checklist 10x Cam Mirror 2x Cam 2 x Side Panels Bolt 2x Cam Lower Shelf Head 6x Wood Upper Shelf Screw 1 x Hex Hanging Hook Metal Hanging Rail Wooden Cam cover 10x Wood 2x Wall Washer Strap 10 x Bolt...
- Page 3 Step by step assembly instructions Step One On a soft, clean and level surface insert 2x cam bolts into the reverse of the mirror. Step Two Attach the Upper Shelf Panel (D) to the Mirror (A) as shown below using 2x Cam heads (K).
- Page 4 Step Three With the aid of an assistant carefully lift the mirror onto its side. Attach 1x Side Panel (B) using the hex key (M) provided. Thread bolt (H) through side panel (B), washer (G) and secure into cam nut (I) in order to attach the side panel (B) into place. Step Four Attach the 1 x Lower Shelf (C) to Side Panel (B).
- Page 5 Step Five With the aid of an assistant carefully turn the mirror over in order to fit the remaining Side Panel (B). Step Six With the aid of an assistant carefully stand the mirror up on to the base. Fit Wooden Cam Covers (N).
- Page 6 Hanging Rail (F) Step Eight Your Mirror is supplied with wall fixing straps which John Lewis would recommend is used to secure the product to the wall. Attach one end of the wall fixing strap to the top of the unit with the screw provided and the other end should be attached to the wall by a competent person using a fixing suitable for your wall.
-
Page 7: Care And Maintenance
Care and Maintenance The John Lewis No 049 bedroom collection is crafted from solid Oak and Oak veneers and then finished with a light lime wash and lacquer. The woods and veneers used in this furniture have been specially selected for their natural beauty and characteristic appearance.
