Satco NUVO SF77-325 Quick Start Manual

150W SINGLE FLOOD FIXTURE
Model: SF77-325
CAUTION: IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT: Read before installing device. Retain for future reference.

CAUTION RISK OF FIRE

USE 150 WATT OR SMALLER 120 VOLT, TYPE PAR38 BULB
Use care when plugging in or handling lamp or cord as you would with any outdoor
electrical equipment. When installing or replacing floodlight be sure gasket is
properly in place for a safe weatherproof installation.
WARNING: This portable lamp has a POLARIZED plug (one blade is wider than
the other). As a feature to reduce the risk of electric shock. This plug will fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician. Never use with an extension
cord unless the plug can be fully inserted. Do not alter the plug. Do not attempt to
defeat this safety feature.
WARNING: When using outdoor use products, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and personal injury,
including the following:

READ ALL INSTRUCTIONS

a) Ground Fault Circuit Interrupter (GFCI) protection is to be provided on the circuit(s)
or outlet(s) to be used for the wet location portable luminaire. Receptacles are
available having built-in GFCI protection and are able to be used for this measure
of safety.
b) Use only with an extension cord for outdoor use, such as an extension cord of
cord type SEW, SEOW, SEOOW, SOW, SOOW, STW, STOW, STOOW, SJEW,
SJEOW, SJEOOW, SJW, SJOW, SJOOW, SJTW, SJTOW, or SJTOOW.

SAVE THIS INSTRUCTION

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
© Copyright 2021 Satco Products, Inc. 3/21
SCREW
OPTION A
SCREW
OPTION B
FLOODLIGHT SOCKET
AND MOUNTING HARDWARE
High-impact fixture resists weather
and wear. Optional spike for lawn use.
Use Par 38 floodlight only.
Max 150 watts/120 volts.
1. Option A: Attached assembled
floodlight securing the wing nut to wall,
floor or ceiling with screw or nail using holes in plate.
2. Option B: To use on lamp, screw the stake with round
plate, fully insert stake only up to indicator line. Set light to
proper angle, direction and securely tighten with wing nut.
3. Plug into outlet or electrical extension cord.
SCREW
WING NUT
WING NUT
SCREW INTO
ROUND PLATE
Satco Products, Inc.
Brentwood, NY 11717
