Icom IC-M88 Service Manual page 25

MP33 (C)
MP31 (C)
MP54 (C)
NOTE 2
MP51 (C)
MP461 (L)
MP52 (C)
NOTE 1
MP53 (C)
MP12 (C)
MP13 (C)
MP1 (C)
NOTE 1 : Once the following parts are removed, an O ring or sealing washer
must be replaced with new one before reattachement.
Daughter parts for
REF. NO. Mother parts
relayted replacement
MP45 (C) Antenna connector (J41) O ring
Sealing washer (W)
MP53 (C) MP52 (C) Screw
MP32 (C) R801 O ring (AB)
NOTE 2
Apply a screw lock in the conclusion with J41 (C) and MP51 (C).
Reference No. : 89500001350
Reference Name : Screw lock 1401B
SP1 (C)
NOTE 1
MP32 (C)
NOTE 3
MP4 (C)
R801 (VR)
NOTE3
VR UNIT
MP6 (C)
W802 (VR)
W801 (VR)
NOTE3
MP5 (C)
MC461 (L)
MP681 (L)
MP462 (L)
MP11 (C)
MP10 (C)
MP7 (C)
MP9 (C)
MP8 (C)
MP71 (C)
MP72 (C)
MP52 (C)
NOTE 3
MP21 (C)
MP53 (C)
MP22(C)
NOTE 1
MP684 (L)
MP23 (C)
NOTE 3 The glue must be applied to the
Manufacture : Cemedine Co.
Type
1
MP7 (C)
7 - 2
DS681 (L) MP682 (L)
EP681 (L)
MP683 (L)
MP101 (M)
MP47 (C)
MP35 (C)
MP42 (M)
MP43 (M)
MP41 (M)
W41 (C)
MP35 (C)
LOGIC UNIT
MP685 (L)
areas when the front panel is replaced with new one, to ensure water tightness.
: Super-X
2
A basis to
install a
speaker
MP11 (C)
Glued
MP11 (C) MP1 (C)
MP1 (C)
Not putting glue to the depths
of a ditch of MP1.
NOTE 1
MP45 (C)
MP44 (C)
MP46 (C)
MP111 (M)
MP151 (M)
MAIN UNIT
MP47 (C)
1
Painting from 2 3
Painting with the
the lower part.
upper part from
MP5 (C)
a crack.
MP4 (C)
MP6 (C)
NOTE 2
J41 (C)
NOTE3
MP42 (C)
MP43 (C)
MP66 (C)
MP65 (C)
MP55 (C)
MP41 (C)
(C) : CHASSIS PARTS
(L) : LOGIC UNIT
(M): MAIN UNIT
(VR): VR UNIT
MP42 (C)
MP41 (C)
