Summary of Contents for Iseki SBC402X
- Page 1 ISEKI DIESEL RIDING MOWER Supplement COLLECTOR: SBC402X FOR SXG15 Lawn Mower...
- Page 2 I. FOR SAFE OPERATION On the collector SBC402X-LE4F COVER/CYLINDER SBC402X-LE4F SBC402X-LAE4F SBC402X-LAE4F (1) Link Caution label (3) Maintenance label (Code No. 8664-905-003-0) (Code No. 1593-901-015-0) Shut off the engine and remove the starter key before performing maintenance or repair work.
- Page 3 Lawn mower (1) Model name and serial number (2) Engine model name and serial number Mower deck (3) Model name and serial number Collector (SBC402X) (4) Model name and serial number Model Type Manual dunp Hydrauric dunp LE4F ...
- Page 4 COLLECTORS Model SBC402X Remarks LE4F LAE4F Type Blower less center collect low dump collector Dimensions overall length (mm) Attached lawn mower overall width (mm) Attached lawn mower overall height (mm) 1343 Attached lawn mower Weight (kg) Container capacity (liters) Height of dump...
- Page 5 SCMA40 b. Move the dump lever(6) downward or push the dump 5. EMERGENCY STOP switch (LAE-type) to dump the collector. • W h e n a n y o f t h e f o l l o w i n g a b n o r m a l i t i e s i s c.
-
Page 6: Names Of Major Components
SBC402X I. NAMES OF MAJOR COMPONENTS 1. SBC402X-LAE4F (Low dump collector with assist cylinder) (1) Collector frame (2) Container (3) Dump cylinder (4) Container frame (5) Upper cover (6) Cleaning stick (7) Attaching bolts (8) Handle (9) Cylinder cover (10) Link cover... - Page 7 II. DETACHING AND ATTACHING COLLECTOR II. DETACHING AND ATTACHING COLLECTOR Warning: When attaching or detaching the collector to the lawn mower: • Place the lawn mower on level, hard ground. • Apply the parking brake securely. • Shift the PTO lever to the STOP ( ) position.
- Page 8 SBC402X Remove Remove c. Undo the four bolts (10) which hold together the cleaning plate (6) and pin COMP (7). d. Remove the cleaning plate (6) from the chute. e. Unplug the Electric connectors (9) of the collector from the main harness.
-
Page 9: Collector Operation
4. OPERATION OF COLLECTOR WITH ASSIST (2) Adjustment position label (4) Collector frame CYLINDER a. Filler rate of container is changed with adjusting the 1) SBC402X-LAE4F adjuster bolt(1). (1) Lock plate b. Check the buzzer of grass limit sensor. Set the starter (2) Pin... - Page 10 In case there is to much clearance between the lock plate (1) and pin (2), readjust the nut/M8 (3) to lower the lock bracket (4). 5. OPERATION OF MANUAL COLLECTOR SBC402X- LE4F Open: Raise the dump lever (1) to release the lock from the lock plate (5).
- Page 11 IV. INSPECTION AND MAINTAINANCE OF MAJOR PARTS IV. INSPECTION AND MAINTAINANCE OF MAJOR PARTS 1. FILLING DIAGRAM Grease up the points mentioned below periodically. SBC402X-LAE4F (Low dump collector with assist cylinder) Ref.No Filling points Lubricants Quantity Dump cylinder Dump link...
- Page 12 SBC402X 2. PERIODICAL INSPECTION TABLE SBC402X-LAE4F and SBC402X-LE4F : If lost or deformed : Inspection, replenishment, and adjustment : If loose, fix : Cannot be clogged Inspection and servicing intervals (hours of operation) Pre- Intervals Judgement Ref.
-
Page 13: Troubleshooting
SBC402X VI. TROUBLESHOOTING Troubles Presumable causes Remedies •Filling rate of container is poor •PTO belts are worn down •Replace belts with new one. •Tension of belt is poor •Check belt and correct it. •Net of container is clogged •Clean. •Shooter is clooged with grass •Clear the clogged grass. - Page 14 SBC402X Overseas Business Division 5-3-14, Nishi-Nippori, Arakawa-ku, Tokyo 116-8541, Japan Phone: (03) 5604-7658 Fax: (03) 5604-7703 OM-SBC402X/-EN-10 1102-01-50 Printed in Japan...
