Page 1 UG0936 User Guide RT PolarFire FPGA Transceiver...
Page 2 About Microsemi ©2021 Microsemi, a wholly owned Microsemi, a wholly owned subsidiary of Microchip Technology Inc. (Nasdaq: MCHP), offers a comprehensive portfolio of subsidiary of Microchip Technology Inc. All semiconductor and system solutions for aerospace & defense, communications, data center and industrial markets.
Page 3: Table Of Contents
Contents 1 Revision History ........... . . 1 Revision 1.0 .
Page 4 5.1.1 Transmit Emphasis and DC Amplitude ......... 103 5.1.2 Impedance (Differential) .
Page 5 Figures Figure 1 Transceiver Lane Overview ............3 Figure 2 Transceiver Receiver .
Page 6 Figure 55 Transceiver Reference Clock Mode Type ......... . . 78 Figure 56 PF_XCVR_REF_CLK With One Single-Ended Input and Single Output Clock .
Page 7 Tables Table 1 Supported Serial Protocols ............2 Table 2 CDR Lock Mode Values .
Page 8: Revision History
Revision History Revision History The revision history describes the changes that were implemented in the document. The changes are listed by revision, starting with the current publication. Revision 1.0 The first publication of this document. Microsemi Proprietary and Confidential UG0936 User Guide Revision 1.0...
Page 9: Overview
Overview Overview ® The RT PolarFire FPGA family includes multiple embedded low-power, performance-optimized transceivers. Each transceiver has both the physical medium attachment (PMA), protocol physical coding sub-layer (PCS) logic, and interfaces to the FPGA fabric. The transceiver has a multi-lane architecture with each lane natively supporting serial data transmission rates from 250 Mbps to 10.3125 Gbps.
Page 10: Figure 1 Transceiver Lane Overview
Overview Transceiver Lane Overview Figure 1 • PCIe Sub-System (PCIESS) Transmit PMA Transmit PCS XCVR_TXP PCIe/PIPE Pre-/Post- Emphasis 8b10b Encoder Out of Band Serializer Transmit PCS/ 64b/6xb Fabric Electrical Encoder Interface Idle PCIe XCVR_TXN PMA Only ÷ 1, 2, 4, 8, 11 Divider Transmit PLL CDR Far-End...
Page 11: Features
Overview Features The RT PolarFire transceiver enables users to quickly build high-speed links that support many standard protocols with the features listed: • Supports data rates from 250 Mbps up to 10.3125Gbps. • Serialization/deserialization width at FPGA fabric interface—8, 10, 16, 20, 32, 40, 64, and 80 bits. •...
Page 12: Functional Description
Functional Description Functional Description The RT PolarFire transceiver (Figure 1, page 3) is divided into four distinct transmit (Tx) and receive (Rx) blocks: • • PCS interface block, including a dedicated PCIe PCS • Transmit PLL (Tx PLL) • Reference clock inputs The high-speed PMA blocks connect to the FPGA fabric through the PCS block.
Page 13: Figure 2 Transceiver Receiver
Functional Description Transceiver Receiver Figure 2 • Reference Clock Network Receive PMA Receive PCS XCVR_RXP PMA Only Monitor 64b/6xb CDR w/DFE Decoder Receive CTLE Polarity Deserializer PCS/ 8b10b Fabric Decoder Interface Signal PCIe/PIPE XCVR_RXN Detect Divider PCIe Sub-System (PCIESS) 3.1.1.1 Receive Input Buffer The receiver provides an external input interface through differential pins, XCVR_RXP/N, as shown in the following figure.
Page 14: Figure 4 Input Signal Path
Functional Description 3.1.1.2 Continuous-Time Linear Equalizers (CTLE) The CTLEs equalize a lane’s low-pass response to compensate for high-frequency losses in that lane, thereby improving the quality of the received signal. This circuit can be adjusted to compensate for any physical lane mismatches. There are two transparent stages of CTLE and a separate pair of stages for the decision feedback equalizer (DFE)/eye monitor receive path.
Page 15 Functional Description 3.1.1.4 Eye Monitor The eye monitor is on-device circuitry to visualize the post-equalization signal quality in the receive path while the data path is still active in the system. The non-destructive eye monitor runs a separate sampler in parallel with the CDR and DFE data sampler. This permits the system to remain operational while the eye monitor is functioning.
Page 16: Figure 5 Cdr Lock Mode Options
Functional Description When BMR mode is selected, LANE_X_CDR_LOCKMODE[1:0] are exposed for CDR mode control. The following table lists the value and the description of the CDR lock mode control bits. CDR Lock Mode Values Table 2 • LANE_X_CDR_LOCKMODE[1:0] Values Mode 2’b00 Not used 2’b01...
Page 17 Functional Description 3.1.1.8 Receiver Calibration The RT PolarFire XCVR receivers include both analog and digital blocks that require calibration to compensate for process, voltage, and temperature (PVT) variations in conjunction with signal integrity. The embedded calibration block of RT PolarFire transceiver performs calibration operations that optimize the performance of the transceiver interconnection.
Page 18: Table 3 Mode Of Operations
Functional Description DFE can also be set in static mode where the user can specify the exact DFE coefficients required by the design. DFE Coefficients are set through PDC commands (see DFE Coefficients, page 97) can be used from the register rather than from calibration. This mode does not expose the CALIB_REQ pin or any of the pins to trigger auto-calibration or incremental calibration.
Page 19: Transmitter
Functional Description example, JESD204B startups with a continuous K28.5 stream, then later shifts to actual 8b10b data. This is a change in data pattern and may impact calibrated DFE coefficients. The RT PolarFire transceiver component is generated by the Libero software to include enhanced receiver management logic to control the proper calibration of the receiver, see Enhanced Receiver Management,...
Page 20: Figure 7 Transmit Output Driver
Functional Description 3.1.2.3 Transmit Output Buffer The following figure shows the transmit output buffer of the transceiver lane, which connects to the PCB via the XCVR_TXP/N output pins. The low-power H-bridge differential output buffer includes a configurable driver for amplitude on the 100  differential load up to a maximum swing of 1 V peak to peak.
Page 21: Enhanced Receiver Management
Functional Description Enhanced Receiver Management Enhanced receiver management (ERM) is implemented in FPGA logic inside the XCVR component. The ERM adds DFE/CDR calibration management, and lock-to-data lock detection capabilities of the PF_XCVR. The RTL is autonomously generated by Libero Software. The generated blocks manage the start-up/on-demand CDR/DFE calibration and fine-grain lock detector with a PMA, 8b10b, and 64b6xb modes of the PF_XCVR.
Page 22: Figure 8 Enhanced Receiver Management In Xcvr Configurator
Functional Description ERM Ports Table 4 • Name Direction Description LANE#_LOS Input LANEx_LOS input which may be asserted from an external source such-as optical SFP during no-signal condition as a means of preventing entry to lock- to-data. This input should be used to control application scenarios where the incoming data stream has enough activity to trigger the LANE#_RX_IDLE but lacks enough transitions to lock the RXPLL.
Page 23: Figure 10 Exposing Rx_Ready_Cdr And Rx_Val_Cdr Pins
Functional Description • On-Demand and First Lock: Select to perform calibration on first lock (after PoR) and on-demand. This option is available for both CDR and DFE configuration of the XCVR. You can trigger calibration on-demand using CALIB_REQ port. The CALIBRATING signal is asserted upon CALIB_REQ assertion and de-asserted when the calibration is completed.
Page 24: Figure 11 Dfe Options
Functional Description Figure 11 • DFE Options Figure 12 • First Lock Calibration Waveform Tx Source device powered-up and transmitting Cannot stop transmitting until RX_VAL rises LANE#_RXD[P-N] Glitches on RX_IDLE is expected for incoming traffic > 5Gbps LANE#_RX_IDLE CDR Status(Internal) LANE#_CALIBRATING LANE#_RX_READY_CDR Calibration takes control of...
Page 25: Figure 13 Disruption Of Serial Rx Data Stream
Functional Description Figure 13 • Disruption of Serial Rx Data Stream Transmitted signal is DC. This condition can be detected within 100uS LANE#_RXD[P-N] Glitches on RX_IDLE is expected for incoming traffic > 5Gbps LANE#_RX_IDLE CDR Status(Internal) LANE#_CALIBRATING LANE#_RX_READY_CDR LANE#_RX_READY (Rx Fine Lock) LANE#_RX_VAL RX_VAL may fall earlier due to 64b6xb framing errors or assetion of PCS_ARSTN from FPGA fabric.
Page 26: Transceiver Pcs Interface Modes
Functional Description Figure 15 • On-Demand Calibration Waveform 1- 10 seconds ** Incoming signal must be appropriate for calibration LANE#_RXD[P-N] Glitches on RX_IDLE is expected for incoming traffic > 5Gbps LANE#_RX_IDLE CDR Status(Internal) Calibration Done LANE#_CALIBRATING LANE#_RX_READY_CDR LANE#_RX_READY_CDR may toggle during calibration LANE#_RX_READY (Rx Fine Lock) LANE#_RX_VAL...
Page 27: 8B10B
Functional Description • 64b6xb: 64b/66b or 64/67b encoding/decoding with gearbox logic. • PIPE: a PHY interface for PCI Express (PIPE) supporting PCIe Gen2. Used with the embedded PCIe core or with the soft-IP hosted in the fabric. See UG0685: PolarFire FPGA PCI Express User for details about the embedded PCIe core solution.
Page 28 Functional Description 3.3.1.1 Word Alignment (Byte Boundary or Comma Detect) The 8b10b PCS block performs the comma code-word detection and alignment operation. The comma character is used by the receive logic to align the incoming data stream into 10-bit words. The alignment comma descriptions (K28.1, K28.5, and K28.7) are defined in section 36.2.4.9 of the IEEE 802.3.2002.
Page 29: Figure 16 8B10B Data Path
Functional Description Figure 16 • 8b10b Data Path TX_DATA[n*8-1:0], TX_K[n-1:0] TXP, TXN Encoder Serializer CONV 4*10 n = 4 TX_CLK divide by 2 div40 n = 8 div80 n is either 4 or 8, depending on configured serial speed FPGA PCS= 8B10B Fabric RX_DATA[n*8-1:0],...
Page 30: Table 6 System Registers Affecting 8B10B Data Path
Functional Description blocks and data path steering. Required system register field setting combinations required for enabling 8b10 lane usage. System Registers Affecting 8b10b Data Path Table 6 • Register Page xls Register Name Field Name Description Required Value pcslane L8_R0 L8_TXENCSWAPSEL Selects between 1000BASE- Optional: 0=1000BASE-...
Page 31: Table 7 8B10B Port List
Functional Description System Registers Affecting 8b10b Data Path Table 6 • Register Page xls Register Name Field Name Description Required Value pma_lane DES_CLK_CTRL DESMODE[2:0] Selects parallel bus width of Must select the 40-bit deserializer interface. wide bus mode for 8b10b functionality (3'd7).
Page 32 Functional Description 8b10b Port List (continued) Table 7 • Port Name Direction Clock Description LANE#_TX_DATA[N:0] Input TX_CLK_[R:G] Encoded user data from the fabric. The send/receive order is low to high byte. LANE#_PCS_ARST_N Input Asynchronous active-low reset for the PCS lane. This reset is responsible for the reset of the 8b10b logic and COMMA word aligner.
Page 33 Functional Description 8b10b Port List (continued) Table 7 • Port Name Direction Clock Description LANE#_RX_READY Output Asynchronous Rises when the enhanced receiver management and CDR completes a fine lock detection to the incoming data transitions and the de-serializer is powered-up. If there is no incoming data to the CDR then the RX_READY is low.
Page 34: 64B66B/64B67B
Functional Description 3.3.2 64b66b/64b67b The 64b66b/64b67b (64b6xb) interface modes are used mainly for 10 Gbps-based protocols, 10G base interface over Ethernet (10GBASE-R/KR), common public radio interface (CPRI) rates of 9.830 Gbps, and 40GBASE-R standards. The 64b/66b encoder is used to achieve DC balance and sufficient data transitions for clock recovery.
Page 35: Figure 17 64B6Xb Data Path
Functional Description 64b6xb Transmit Data Path Blocks, Fabric to PMA Order Table 8 • Tx Block Purpose Tx Disparity Implements inversion of 67-bit symbol. Only for use in Interlaken. Tx Gearbox Outputs continuous stream of 32-bits per clock beat to the PMA given an input consisting of 64-bit block symbols, which has cyclic gaps in its active clock beats.
Page 36: Table 10 System Registers Affecting 64B6Xb Data Path
Functional Description 3.3.2.2 64b6xb System Registers There are specific registers used for configuring the 64b6xb lane function options in the PolarFire Device Register Map. Other fields are required to properly program the clocks, resets, XCVR, and lane overlay blocks and data path steering. Required system register field setting combinations required for enabling 64b6xb lane usage.
Page 37: Figure 18 64B66B Receive Sequence For 32-Bit Interface
Functional Description 3.3.2.3 64b66b Receiver The receiver takes 32-bits or 64-bits of data from the PMA's CDR on each clock beat into the gearbox. The gearbox frames the data into 66-bit symbols by searching for valid values on the sync header bits as per IEEE 802.3 Clause 49.
Page 38: Figure 20 64B66B Transmit Sequence For 64-Bit Interface
Functional Description 3.3.2.4 64b66b Transmit In the transmit direction, the encoded 64-bit blocks are applied to PCS data from the fabric along with the sync headers. When the 64-bit symbol is a control block, like Idle, Start or Terminate, then pcs_hdr[1:0]=0b10.
Page 39: Figure 22 64B67B Transmit Sequence For 32-Bit Interface
Functional Description 3.3.2.5 64b67b Transmit In the recommended configuration for 64b67b, encoded and scrambled data is presented from the fabric into TX_DATA along with sync headers on TX_HDR[3:0]. The data from the fabric must conform to the expected sequence of clock beats according to the fabric interface width. Figure 22 •...
Page 40: Figure 23 64B67B Receive Sequence For 32-Bit Interface
Functional Description Figure 23 • 64b67b Receive Sequence For 32-Bit Interface Sequence timing for the 64-bit interface consists of 67 clock beats with dead cycles at beats 22, 44, and The following table lists the port names and description for the 64b66b/64b67b mode of the PCS module. See section 49.2.4 of the for more information.
Page 41 Functional Description 64b66b/64b67b Port List (continued) Table 11 • Port Name Direction Clock Description LANE#_TX_ELEC_IDLE Input Asynchronous Transceiver configurator allows pin to be exposed on component. This input forces XCVR_P/N transmit output pad pair to a common-mode voltage. It is used for low-frequency out-of-band signaling, or to signal entry into a low-power state to the link partner.
Page 42: Pipe
Functional Description 64b66b/64b67b Port List (continued) Table 11 • Port Name Direction Clock Description LANE#_RX_READY Output Rises when the enhanced receiver management and CDR completes a fine lock detection to the incoming data transitions and the de-serializer is powered-up. If there is no incoming data to the CDR then the RX_READY is low.
Page 43 Functional Description The PIPE interface is used by the embedded PCIESS or can be used with a soft PCIe IP in the FPGA fabric. The embedded PCIESS is accessed through a dedicated interface to the PIPE interface mode, which ties the PCIESS to the PIPE without additional fabric logic. The PIPE PCS is used as the interconnection between either the embedded PCIe block or used with a fabric-based soft-IP connected to the transceiver PMA.
Page 44: Table 12 Pipe Port List
Functional Description PIPE Port List (continued) Table 12 • Port Name Direction Clock Description LANE#_TXCOMPLIANCE Input TX_CLK_[R:G] When asserted, this ordinarily forces the currently running disparity to negative. As the name implies, this is useful in conjunction with the transmission of the compliance pattern to generate test data.
Page 45 Functional Description PIPE Port List (continued) Table 12 • Port Name Direction Clock Description LANE#_TXSWING Input TX_CLK_[R:G] Controls transmitter voltage swing: 0: Full swing 1: Half swing LANE#_RXPOLARITY Input TX_CLK_[R:G] This active-high signal indicates the PHY to do a polarity inversion on the received data.
Page 46 Functional Description PIPE Port List (continued) Table 12 • Port Name Direction Clock Description LANE#_RXSTATUS[2:0] Output RX_CLK_[R:G] Delivers receiver status and error codes for the received data and receiver detect status from the PHY to the MAC; for example, SKP symbol added or removed, disparity error, elastic buffer overflow or underflow, 8b10b decode error, and so on.
Page 47: Pipe Interface Compliance Exceptions
Functional Description PIPE Port List (continued) Table 12 • Port Name Direction Clock Description PIPE_CLOCK Output In PCIe Gen1/Gen2 modes of Soft PIPE PCS setting, there is only one TX_CLK_[R:G] for all the 4 lanes that could be configured in single XCVR configurator instance, that is, LANE0_TX_CLK_[R:G] (renamed as PIPE_CLOCK).
Page 48: Pma Only
Functional Description The following figure shows how the soft PIPE interface signals behave when the first detection finds a connected receiver. The difference between receiver presence and absence is the value of RxStatus in simulation, but in real silicon, the delay to the PhyStatus pulse can be different. In real silicon, the Receiver-Not-Present response occurs earlier than a Receiver-Present response.
Page 49: Figure 27 Pma-Bus Waveform
Functional Description Figure 27 • PMA-Bus Waveform LANE#_TX_CLK TX Data LANE#_TX_DATA LANE#_TXD_PIN b0 b1 b2 b38 b39 Figure 28 • PMA Only Data Path – 80-bits TX_DATA[79:0] TXP, TXN Serializer CONV n==4 TX_CLK divide by 2 Div40 n==8 n is either 4 or 8, depending on configured serial speed FPGA PCS- PMA Only-80bit Fabric...
Page 50: Figure 29 Pma Only Data Path - Less Than Or Equal To 40-Bits
Functional Description Figure 29 • PMA Only Data Path – Less Than or Equal to 40-bits TX_DATA[N:0] TXP, TXN Serializer 8, 10, N= 8, 10, div8, 16, 20, 16, 20, div10, div16, 32, 40 32, 40 div20, div32, div40 TX_CLK FPGA PCS-PMA Only- Native Fabric...
Page 51 Functional Description PMA Port List (continued) Table 13 • Port Name Direction Clock Description LANE#_TX_ELEC_IDLE Input Asynchronous Transceiver configurator allows pin to be exposed on component. This input forces XCVR_P/N transmit output pad pair to a common-mode voltage. This can be used for low-frequency out-of-band signaling, or to signal entry into a low-power state to the link partner.
Page 52: Pcs/Fpga Fabric Interface
Functional Description PMA Port List (continued) Table 13 • Port Name Direction Clock Description LANE#_RX_READY Output LANE#_RX_READY rises when the enhanced receiver management and CDR completes a fine lock detection to the incoming data transitions and the de-serializer is powered-up. If there is no incoming data to the CDR then the RX_READY is low.
Page 53: Non-Deterministic Interface
Functional Description Note: Global-Shared mode allows the global clock output from one lane to be used for other lanes. This clocking mode is used when several lanes are part of the same protocol using the same clock. When Global-Shared mode is enabled, all the lanes include a global clock output port, but only one lane can be used as the master port.
Page 54: Figure 31 Non-Deterministic Interface With Fwf
Functional Description In the transmit direction, data from the fabric or PCS is passed through the FWF with a clock from the FWF ensuring synchronous clock and data relationships passing to the PMA interface. The FWF is optionally selected in the Libero Transceiver Configurator by choosing the correct global or regional interface clock option, see Table 32, page 88.
Page 55: Deterministic Interface
Functional Description 3.4.2 Deterministic Interface Low-latency regional clocks with a specific mode of the FWF are used when a zero-cycle path is required; for example, by protocols such as CPRI and JESD204B that require both receive and transmit paths have a fixed deterministic latency as expressed in number of clock cycles. In this case, data is interfaced directly to capture registers while the clock is routed on regional clock resources.
Page 56: Transceiver Clock Regions
Functional Description Figure 36 • Deterministic Transceiver Receive Timing Waveform RX_CLK RX_CLK (at fabric FF) RXDATA Valid Note: RXCLK_FABRIC at PCS I/F after Regional clock route 3.4.3 Transceiver Clock Regions Two regional clock buffers per transceiver lane (eight per transceiver quad) come from the transceiver. These interconnections are the basis for specific regions that the particular Quads can drive.
Page 57: Transceiver Data Path Latency
Functional Description Users need to understand the regional clock implications when targeting designs that may migrate to different device sizes. The user should also use this in pin planning of boards when desiring to drive I/O from the transceiver clocks. Table 14 •...
Page 58: Transceiver Clocking
Functional Description The following table lists the transceiver interface clocking use cases in the Libero SoC software, which uses presets per protocol. See PCS/FPGA Fabric Interface, page 45 for explanation of system clock source modes. Table 16 • Transceiver Interface Clocking Use Cases Preset Width System Clock Source...
Page 59: Transmit Pll
Functional Description which provides the necessary clocks for the XCVR_LANE or XCVR_LANES. The XCVR_TXPLL synthesizes the input reference clock to generate the high-speed serial clock used in the transmitter PMA. XCVR_REF_CLKs and XCVR_TXPLLs are shared and used for several high-speed serial protocols.
Page 60: Table 17 Transmit Pll
Functional Description Q#_TXPLL_SSC: This PLL operates in the 1.6 GHz – 6.4 GHz frequency range and can provide a transmit bit clock to a transceiver quad. The TxPLL_SSC supports jitter attenuation for loop-time applications. Unique to this PLL is the spread-spectrum clocking (SSC) generation support, which can generate a saw-tooth clock with various options.
Page 61: Spread Spectrum Clocking
Functional Description 3.5.2 Spread Spectrum Clocking TxPLL produces spread spectrum clock generation (SSCG). SSCG uses a modulated output clock signal to reduce peak EMI. The lowering of peak EMI enables significant reduction in expensive shielding cost or reduce interference with other sensitive circuits. By modulating the PLL, the resulting spectrum at each clock harmonic is made broad-band or flattened, and reduced in amplitude from 10 db to 20 dB, depending on frequency and modulation amplitude.
Page 62: Transmit Lane Alignment
Functional Description 3.5.3 Transmit Lane Alignment Applications like Serial RapidIO, XAUI, DisplayPort, Interlaken, and JESD204B need transmit alignment across multiple lanes. Transmit lane alignment depends on the number of lanes, total skew, fabric clock frequency relative to the line rate, and number of TX PLLs. The method of alignment involves launching a reset from the shared PLL to each TX lane after the PLLs are locked.
Page 63: Figure 41 Using Txplls For Upto Four Lanes
Functional Description Figure 41 • Using TXPLLs For Upto Four Lanes TX_Bit_CLK TXPLL1 TX_CLK_RESET QUAD TX_Bit_CLK TX Lane TX_CLK_RESET TX_Bit_CLK TX_Bit_CLK TX Lane TX_CLK_RESET TXPLL_SSC TX_Bit_CLK TX_CLK_RESET TX Lane TX_CLK_RESET TX_Bit_CLK TX Lane TX_CLK_RESET TX_Bit_CLK TXPLL0 TX_CLK_RESET QUAD TX_Bit_CLK TX Lane TX_CLK_RESET TX_Bit_CLK TX_Bit_CLK...
Page 64: Figure 42 Fpga Logic For Tx Alignment (5 To 8 Lanes)
Functional Description In these scenarios, the transceiver uses two PLLs with the same reference clock and a separate fabric logic for reset of the TX lanes as shown in Figure 42, page 57. Figure 42 • FPGA Logic For TX Alignment (5 to 8 Lanes) PF_XCVR Any low skew clock not from Tx or Rx SerDes lane clocks that is at the same rate or slower...
Page 65: Transceiver Clocks
Functional Description 3.5.4 Transceiver Clocks The transceiver transmitters have high-performance bit clocks running at half the line rate of the fastest transmit lane driven by the clock. The transmit PLLs generate these clocks based on a transmit reference clock, with the configuration set in the Libero design software. Within each lane, the transmit bit-rate clock (Figure 6, page 12) is divided by 1 (full rate), 2, 4, 8, or 11 to...
Page 66: Figure 43 Reference Clock (Refclk) Interface To Transmit Pll
Functional Description Figure 43 • Reference Clock (REFCLK) Interface to Transmit PLL Cascade from Upper REFCLK To Local Quad CDRs TXPLL PLL_LOCK REFCLK0 REF_CLK LOCK CLKS_TO_XCVR[BIF] REFCLK1 BIT_CLK REF_CLK_TO_LANE TXPLL= TXPLL_SSC or REFCLK TXPLL0 or TXPLL1 Interface Cascade to Lower The following table lists the transmit PLL pins.
Page 67: Figure 44 Typical Jitter Attenuator Application Scheme
Functional Description There are some use-cases which can allow a XCVR quad's global output to be used to broadcast the SerDes REFCLK, if that XCVR is configured to use regional clocks for the TX/RX clocks allowing these specific use-cases to broadcast the SerDes REFCLK into the FPGA fabric with a more predictable amount of clock jitter.
Page 68: Figure 45 Jitter Attenuation Txpll
Functional Description Select Jitter Cleaning Mode under the Clock Options and choose the targeted protocol templates from the drop-down as shown in the following figure. Figure 45 • Jitter Attenuation TXPLL Jitter attenuation PLL presets can be selected with TX PLL configurator (and the enable JA_CLK port in XCVR configurator).
Page 69: Figure 46 Japll Custom Protocol Setting
Functional Description 3.5.4.2.1 Custom Protocol Settings Full duplex jitter attenuation solution is available for custom protocols in Libero SoC v12.3 or later. This support is for one refclk and one data rate allowing user the flexibility to create designs requiring customized settings not already supported by the presets.
Page 70: Figure 49 Dedicated Transceiver Reference Clock Inputs
Functional Description 3.5.4.3 Dedicated Reference Clock Input Pins For every transmit PLL within the transceiver PMA, there is a reference input pin pair for an external input of reference clocks to the device, as shown in the following figure. The reference clock inputs provide flexibility to interface with both single-ended and differential clocks and can drive up to two independent clocks per transceiver quad.
Page 71: Table 20 Xcvr Refclk Defaults
Functional Description 3.5.4.3.2 Reference Voltage Input In this mode, the input interface supports two single-ended modes: • Local reference input: a reference voltage is connected to the XCVR_REFCLK_N input, which is used for the clock connected to the XCVR_REFCLK_P input. The resulting reference clock is available on the REFCLK0 output (REFCLK1 output is unavailable with local reference input mode).
Page 72: Figure 50 Refclk Input Pin Diagram
Functional Description Reference clock input buffer Standards Table 21 • Reference voltage (Not supported Single ended Differential for ES/XT devices). LVCMOS18 (VDDI = 2.5) HCSL25 HSUL18I (VDDI = 2.5) LVCMOS25 (VDDI = 2.5) LVDS25 HSUL18II (VDDI = 2.5) LVCMOS33 (VDDI = 3.3) LVPECL33 (VDDI = 3.3) SSTL18I (VDDI = 2.5) LVTTL (VDDI = 3.3)
Page 73: Table 22 Rt Polarfire Transceiver Resources
Functional Description Note: The XCVR_#[ABC]_REFCLK pins are available per quad. The REFCLK input to the reference clock interface (see Figure 43, page 59) connects the REFCLK source to the associated TxPLL. For more information on reference clock interface, see Transceiver Reference Clock Interface, page 58.
Page 74: Figure 51 Rtpf500T Transceiver And Transmit Pll Layout
Functional Description Figure 51 • RTPF500T Transceiver and Transmit PLL Layout Q4_LANE3 Q4_LANE2 Q4_TXPLL Q4_LANE1 Q4_LANE0 Q4_TXPLL_SSC Q2_TXPLL0 Q2_LANE3 Q2_LANE2 Q2_TXPLL_SSC Q2_LANE1 Q2_LANE0 Q2_TXPLL1 PCIE1 Q0_TXPLL1 Q0_LANE3 Q0_LANE2 Q0_TXPLL_SSC Q0_LANE1 Q0_LANE0 Q0_TXPLL0 PCIE0 Q1_TXPLL0 Q1_LANE3 Q1_LANE2 Q1_TXPLL_SSC Q1_LANE1 Q1_LANE0 Q1_TXPLL1 Q3_LANE3 Q3_LANE2 Q3_TXPLL_SSC...
Page 75: Pma And Pcs Resets
Functional Description PMA and PCS Resets The RT PolarFire transceiver uses partitioned resets, one single wire for PMA_ARST_N and one for PCS_ARST_N to the PF_XCVR. Specifically, these two inputs can come from the FPGA fabric to reset the PMA and PCS portions of the transceiver. Both inputs assert the reset asynchronously and de- assertion is internally synchronized.
Page 76: Pcs Rate Switch Between 8B10B And 64B66B Mode For Cpri
Functional Description PCS Rate Switch Between 8b10b and 64b66b Mode for CPRI All CPRI protocol data rates are statically supported with the Libero Transceiver Configurator using either 8b10b or 64b66b modes. 8b10b supports CPRI rates 2, 3, 4, 5, 6, and 7 while 64b66b mode supports rates 7a, 8, and 9.
Page 77 Functional Description Port Crossover between the 8b10b and 64b66b Modes Table 23 • DIRECTION 8B10B MODE 64B6xB MODE Input TX_DISPFNC[0] RESERVED_IN[13] Input TX_K[7:6] RESERVED_IN[15:14] Input TX_K[5] RESERVED_IN[16] Input TX_K[4] TX_SOS Input TX_K[3:0] TX_HDR[3:0] Input TX_DATA[63:33] TX_DATA[63:33] Input TX_DATA[32:19] TX_DATA[32:19] Input TX_DATA[18:17] TX_DATA[18:17] Input...
Page 78 Functional Description Port Crossover between the 8b10b and 64b66b Modes Table 23 • DIRECTION 8B10B MODE 64B6xB MODE Output RX_DATA[63:51] RX_DATA[63:51] Output RX_DATA[50:49] RX_DATA[50:49] Output RX_DATA[48:9] RX_DATA[48:9] Output RX_DATA[8:5] RX_DATA[8:5] Output RX_DATA[4] RX_DATA[4] Output RX_DATA[3:1] RX_DATA[3:1] Output RX_DATA[0] RX_DATA[0] Input TX_BIT_CLK* Input TX_PLL_LOCK*...
Page 79: Table 24 System Registers Affecting 8B10B And 64B6Xb Data Paths
Functional Description The following table outlines the affected registers that must be modified during rate switching. System Registers Affecting 8B10B and 64B6xB Data Paths Table 24 • Register Required Value for Required Value for Page xls Register Name Field Name Description 8B10B 64B6xB...
Page 80 Functional Description System Registers Affecting 8B10B and 64B6xB Data Paths (continued) Table 24 • Register Required Value for Required Value for Page xls Register Name Field Name Description 8B10B 64B6xB pcslane LCLK_R0 LCLK_PCS_RX Defines clock Must be set to 2’d3 for 2’d3 _CLK_SEL [1:0] module’s source for...
Page 81 Functional Description System Registers Affecting 8B10B and 64B6xB Data Paths (continued) Table 24 • Register Required Value for Required Value for Page xls Register Name Field Name Description 8B10B 64B6xB pma_lane DES_CLK_CTRL DESMODE[2:0] Selects parallel bus Must select the 40-bit Must select the 32- width of deserializer wide bus mode for...
Page 82: Implementation
Implementation Implementation RT PolarFire transceiver blocks support many high-speed serial protocols. These protocols are supported using multiple transceiver building blocks that the user constructs using the transceiver configurators in the Libero design software. The Libero configurator allows the user to set the reference clock and data rates for particular protocols.
Page 83: Transceiver Reference Clock Configurator
Implementation 4.1.1 Transceiver Reference Clock Configurator The Transceiver Reference Clock Configurator is used to build the correct reference clock input to the transceiver and to the Tx PLL. The user can pick the input type and various input options. To initiate the Reference Clock Configurator, perform the following steps: Access the Transceiver Reference Clock cores under PolarFire Features from the Catalog window, as shown in the following figure.
Page 84: Figure 54 Transceiver Reference Clock Configurator Gui
Implementation Figure 54 • Transceiver Reference Clock Configurator GUI The following tables lists transceiver reference clock configurator GUI options. Transceiver Reference Clock Configurator GUI Options Table 26 • Options Default Details Reference Clock 0 configuration Enable reference clock 0 Enable and disable Enabled Checked = enabled Reference Clock 0 Mode...
Page 85: Figure 55 Transceiver Reference Clock Mode Type
Implementation Select the reference clock mode type based on the input buffer type in the application. Single-ended Differential is the default mode. Figure 55 • Transceiver Reference Clock Mode Type In the case of LVCMOS or Voltage Reference inputs, the design can have up to two individual reference clock inputs in one instance of the PF_XCVR_REF_CLK.
Page 86: Figure 58 Pf_Xcvr_Ref_Clk With Differential Input And Single Output Clock
Implementation Figure 58 • PF_XCVR_REF_CLK With Differential Input and Single Output Clock Optionally enable a connection to the FPGA fabric for either/both reference clock 0 or reference clock 1. When enabled, a related port of the associated reference clock is exposed for fabric routing. Figure 59 •...
Page 87: Transmit Pll Configurator
Implementation 4.1.2 Transmit PLL Configurator The Transceiver Transmit PLL Configurator is used to build the correct transmit PLL to the transceiver. The user can pick from many of the PLL options used for the transceiver based on the application. To initiate the Transceiver Transmit PLL Configurator, perform the following steps: Access the Transmit PLL module under PolarFire Features from the Catalog window, as shown in the following figure.
Page 88: Figure 61 Transmit Pll Configurator Gui
Implementation Double-click each PF_TX_PLL block from the catalog to launch the configurator. A GUI allows the option of selecting the related transmit PLL properties. Figure 61 • Transmit PLL Configurator GUI The following table lists the transmit PLL configurator GUI options. Transmit PLL Configurator GUI Options Table 27 •...
Page 89: Figure 62 Clock Inputs
Implementation Transmit PLL Configurator GUI Options Table 27 • Clock Inputs Options Default Details Jitter Cleaning Mode Enable and disable Disabled Radio-button on = disabled The following options are available when enabled: 10G SyncE 32Bit 10G SyncE 64Bit 1G SyncE 10Bit CPRI Rate 1 CPRI Rate 2 CPRI Rate 3...
Page 90: Figure 64 Clock Options
Implementation Normal Mode configures the TX PLL to default operation based on the clock Inputs/Outputs setting. Whereas, Jitter Cleaning mode customizes the attenuation coefficients for the pre-defined standards to be used where the recovered clock can be used as a TX reference clock to meet protocol jitter specifications.
Page 91: Figure 67 Enable Dynamic Reconfiguration Interface
Implementation Spread Spectrum Table 28 • Options Default Details Modulation Frequency Target User entry 64 KHz Target Spread Spectrum modulation. Calculated 60.0962 KHz Calculation is based on TXPLL reference clock settings. Spread Mode Down spread/Center Down Configures the modulation style Spread Spread/Divval Spread...
Page 92: Transceiver Interface Configurator
Implementation The TxPLL supports an additional clock output. This CLK_125 output port is automatically exposed when TxPLL BIT_CLK is 5 Gbps. This clock is used with the PCIE macro as input to the transaction layer or AXI clock. For more information about CLK_125, see UG0685: PolarFire FPGA PCI Express User Guide.
Page 93: Figure 70 Transceiver Interface Configuration Gui
Implementation Double-click each PF_XCVR block in the catalog to launch the configurator. A GUI allows the option to select the related XCVR properties. Figure 70 • Transceiver Interface Configuration GUI The following tables list Transceiver Interface options. Table 29 • Transceiver Interface General Settings General Options...
Page 94 Implementation Transceiver Interface PMA Settings Table 30 • PMA Settings Options Default Details TXPLL base data rate Computed TX PLL bit clock frequency Computed RX Data rate 250 Mbps – 10.3125 Gbps 5000 Mbps 10312.5 Mbps (STD maximum) RX CDR lock mode Lock to reference, Lock to data, Lock to data Burst Mode Receiver...
Page 95: Table 31 Transceiver Interface Pcs Settings
Implementation Transceiver Interface PCS Settings (continued) Table 31 • PCS Settings Options Default Details Soft PIPE interface PCIe Gen1 (2.5Gbps) PCIe Gen1 (2.5 Gbps) PCIe Gen2 (5.0Gbps) Dependent on PCS settings. TX_CLK_G/R frequency = RX_CLK_G/R frequency = FPGA Interface frequency = data rate/(PMA-PCS width × PCS Gearing). Clocks and Resets Table 32 •...
Page 96: Figure 71 Pma Mode-Enable Cdr Bit-Slip Port
Implementation LANE#_TX_BIT_CLK_0, and LANE#_TX_PLL_LOCK_# are included in CLKS_FROM_TXPLL_# BIF (bus interface). This connection is required between the TXPLL and Transceiver Interface. Select the desired CDR reference clock mode and CDR reference clock frequency from the drop-down list based on the application. Note: CDR reference clock frequency drop-down list is populated with valid frequencies based on the data rate.
Page 97: Figure 74 Xcvr Component With Dri Port Enabled
Implementation Figure 74 • XCVR Component With DRI Port Enabled 12. After making all of the selections in the Transceiver Interface Configurator, click OK. When the transceiver interface configuration is complete, a PF_XCVR macro is generated by the Libero Software. The macro includes the ports based on the configuration. Figure 76, page 91 to Figure 79,...
Page 98: Figure 76 Pma Only Pcs Example Smartdesign Component
Implementation Figure 76 • PMA Only PCS Example SmartDesign Component Figure 77 • 8b10b PCS Example SmartDesign Component Figure 78 • 64b66b PCS Example SmartDesign Component Microsemi Proprietary and Confidential UG0936 User Guide Revision 1.0...
Page 99: Figure 79 Soft Pipe Pcs Example Smartdesign Component
Implementation Figure 79 • Soft PIPE PCS Example SmartDesign Component After building the PF_XCVR, PF_TX_PLL and PF_XCVR_REF_CLK cores, the transceiver subsystem must be connected together in the SmartDesign canvas. Typically, the REF_CLK and/or FAB_REF_CLK outputs of the PF_XCVR_REF_CLK are connected to the respective inputs of the PF_XCVR and the input REF_CLK of the PF_TX_PLL.
Page 100: Transceiver Modes
Implementation Figure 81 • Completed Transceiver Subsystem with ERM See the port list tables in Transceiver PCS Interface Modes, page 19 for complete pin descriptions generated with the Transceiver Configurator. Transceiver Modes The transceiver architecture permits several ways to use the transmit and receive portions of the PMA and PCS.
Page 101: Full-Duplex Mode
Implementation 4.2.1 Full-Duplex Mode Tx and Rx Duplex support is the most common use of the transceiver and often referred to as full-duplex. It is defined as the mode where the Rx and Tx portions of the PMA share resources such as clocking and reset functions.
Page 102: Libero Generated Files
Implementation If the TXPLL uses Frac-N rather than integer-based to synthesize the bit clock, the CDR PLL will not have the Frac-N capability. Consequently, the user needs to determine if the PPM tolerance of the CDR is enough to compensate for the TXPLL rate. Libero Generated Files Libero SoC software automatically generates the required files after stepping through the design entry steps of the transceiver.
Page 103: Figure 83 Derive Constraints Using Constraints Editor
Implementation create_clock -period <T> [get_pins {LANE<n>/RX_CLK_R}] Users need to use the Derived SDC file generated by clicking the Derive Constraints in the Timing tab of the Constraint Manager window of Libero SoC software. The following example shows a Libero project with transceiver. create_clock -name {REF_CLK_PAD_P} -period 6.4 [ get_ports { REF_CLK_PAD_P } create_clock -name {My_Project_0/my_xcvr_0/PF_XCVR_0/LANE0/TX_CLK_R} -period 16 [ get_pins { My_Project_0/my_xcvr_0/PF_XCVR_0/LANE0/TX_CLK_R } ]...
Page 104: Physical Constraints
Implementation 4.4.2 Physical Constraints Transceiver designs require physical constraints. These constraints provide placement guidance for the embedded transceiver blocks such as XCVR_REF_CLK, XCVR_TXPLL, and XCVR. Select the placement of the RXD and TXD transceiver pins and reference clock input pins by adding location constraints to the design PDC file.
Page 105: Adding Physical Constraints Using Libero
Implementation To set the required registers with static values, users must enhance the “set_io” PDC command to add new attributes. The new attributes that need to be added are highlighted in the below PDC command. PDC command example: set_io -port_name LANE0_RXD_N -RX_DFE_COEFFICIENT_H1 -RX_DFE_COEFFICIENT_H2 -RX_DFE_COEFFICIENT_H3...
Page 106: Invoking The Pin Planner
Implementation 4.5.1 Invoking the Pin Planner To invoke the Pin Planner, the design must be in the post-synthesis state. Invoke the Constraint Manager from the Design Flow window (Design Flow > Manage Constraints > Open Manage Constraints View). In the Constraints Manager, select the I/O Attributes tab and then select Edit > Edit with I/O Editor (I/O Attributes >...
Page 107: Figure 85 Xcvr Placement Tab
Implementation Figure 85 • XCVR Placement Tab The following figure shows the XCVR Signal Integrity View tab. When user selects lane in Left Panel, the user can view and change the signal integrity parameters for the Rx and Tx transceiver ports. Figure 86 •...
Page 108: Transceiver Initialization
Implementation Transceiver Initialization The transceiver is initialized after the user customizes the transceiver or PCIe features with the associated configurators. The transceiver initialization data refers to the memory files and the initialization clients required for the three stages of initialization that is executed by the device at start-up. For proper functioning, the user design must generate initialization data before programming (running Generate Bitstream or the Export Programming File, Export Programming Job, Export Programming Job Data, Export SmartDebug Job Data, Generate SPI Flash Image, Generate SPI Flash Image, and Export...
Page 109: Signal Integrity Conditioning
Signal Integrity Conditioning Signal Integrity Conditioning The RT PolarFire transceivers have many tuning adjustments for the analog portions of the PMA allowing for signal integrity optimizations to the system. These features include Rx Continuous Time Line Equalization (CTLE), Rx termination, polarity inversion, Pre- and Post-cursor output emphasis, output impedance settings, and Tx amplitude adjustment.
Page 110: Transmitter
Signal Integrity Conditioning Building a transceiver based design using Libero SoC software flow allows flexibility to improve the RT PolarFire transceiver performance within the system. The RT PolarFire software sets initial good defaults for the user's custom design based on input information to the transceiver configurators. The user can change the associated transceiver input and output settings using the IO Editor after initial design generation.
Page 111: Receiver
Signal Integrity Conditioning Receiver The receiver deserializes high-speed serial data received through the input buffer by creating a parallel data stream for the FPGA fabric and recovering the clock information from the received data. For more information about receiver, see Receiver, page 5.
Page 112: Loss-Of-Signal Detector
Signal Integrity Conditioning 5.2.5 Loss-of-Signal Detector Loss-of-signal (LOS) detector (low and high value) sets the requirement of the voltage detector. The following table lists the upper and lower set points for a LOS to ensure that a good signal is applied into the receiver.
Page 113: Io Editor-Signal Integrity
Signal Integrity Conditioning 5.3.1 IO Editor—Signal Integrity To access the Signal Integrity tab from IO Editor: Open Constraint Manager > Edit > Edit with I/O Editor. Figure 88 • IO Editor—XCVR View In the XCVR View [active] tab, select Signal Integrity View tab and the XCVR lane to edit signal integrity settings as shown in the following figure.
Page 114: Table 37 Tx Attributes And Values
Signal Integrity Conditioning 5.3.2.1 PDC Supported Attributes and Values The following table list the PDC supported attributes and values. For more information about he description of the attributes, see Transmitter, page 103. Table 37 • TX Attributes and Values Name Direction Values Default...
Page 115: Table 38 Rx Attributes And Values
Signal Integrity Conditioning TX Attributes and Values Table 37 • Name Direction Values Default TX_TRANSMIT_COMMON_MODE_ Output ADJUSTMENT The following table list the PDC supported attributes and values. For more information about he description of the attributes, see Receiver, page 104. Table 38 •...
Page 116 Signal Integrity Conditioning RX Attributes and Values (continued) Table 38 • Name Direction Values Default RX_LOSS_OF_SIGNAL_ Input DETECTOR_HIGH PCIE SATA POLARITY Input Normal Normal Inverted Microsemi Proprietary and Confidential UG0936 User Guide Revision 1.0...
Page 117: Smartdebug Signal Integrity
Signal Integrity Conditioning SmartDebug Signal Integrity SmartDebug signal integrity is invoked from debug transceiver. SmartDebug Signal Integrity helps to evaluate the reliability of a high-speed serial link using RT PolarFire transceivers. The signal integrity GUI follows the same format as the IO Editor. For more information about software operation, Guide.
Page 118: Loopback Modes
Signal Integrity Conditioning 5.4.1 Loopback Modes Loopback operations are embedded within the RT PolarFire XCVR and are commonly used in debug practice. These loop backs can be tested solely within the device by sending and receiving on-chip or can test real-data to and from the system side. For information, see Loopback, page 116.
Page 119: Eye Monitoring
Signal Integrity Conditioning Monitor the Lock indicators and error counters to check the quality of the link. This test ensures proper power supplies, clocks and resets to the XCVR and traffic is not going off-chip to the system. The following figures show the Smart BERT options of the debug transceiver. Figure 92 •...
Page 120: Figure 94 Eye Monitor Plot
Signal Integrity Conditioning The plot produces an eye diagram by overlaying many bits whereas a color gradient shows the density hits of the signal. Thus, the opening is represented as the area with least hits. Click the Eye Monitor tab in the Debug TRANSCEIVER window to see the eye monitor representation within the receiver.
Page 121: Figure 95 Example Of Optimize Dfe
Signal Integrity Conditioning 5.4.3.2 SmartDebug Decision Feedback Equalization Support SmartDebug is used to adapt the DFE coefficients to optimize the settings for the overall signal integrity at the receiver for the system under test environment. On-demand, the SmartDebug utility runs the adaptive algorithm to of the DFE filter to resolve the TAP values of the DFE coefficients.
Page 122: Simulation
Simulation Simulation RTL simulation mode is available for all of the transceiver modes. This simulation mode enables the simulation of all the protocol communication layers (including the PMA, PCS, and fabric interfaces) and provides accurate cycle simulation for the design. However, using RTL simulation incurs some run-time penalties.
Page 123: Debug And Testing
Debug and Testing Debug and Testing RT PolarFire FPGA include debug and testing features for multi-gigabit transceivers. It provides capabilities for diagnostic test setups and inserting test patterns during FPGA testing and debugging. This chapter describes the embedded transceiver capabilities that allow high-speed link diagnostics. PRBS Generator/Checker Each RT PolarFire FPGA transceiver has embedded blocks with a built-in PRBS generator and checker that can be used to perform link testing and diagnostics.
Page 124: Figure 97 Transceiver Loopbacks
Debug and Testing This loopback is after the CDR which requires the receive and transmit paths to have exactly matched clock rates or 0 ppm differences. This loopback supports the full data rates of the transceiver. In the Far-end loopback case, the LANE#_RX_READY must be used instead of LANE#_RX_VAL to indicate valid data path.
Page 125: Dynamic Reconfiguration Interface
Debug and Testing Dynamic Reconfiguration Interface The dynamic reconfiguration interface (DRI) is used with RT PolarFire transceiver to access the memory map of the transceiver blocks. DRI is an APB slave that allows global access to all transceiver lanes, PCIe blocks, transmit PLLs, and FPGA PLLs. The DRI allows changing key features of the transceiver before and during operation.
Page 126: Board Design Recommendations
Board Design Recommendations Board Design Recommendations User must have knowledge of the following PCB design topics before designing a PCB that uses RT PolarFire transceivers. • Device interfacing • Transmission line impedance and routing • Power supply design filtering and distribution •...
Page 127 Board Design Recommendations Transceiver Device Level Pin List (continued) Table 39 • Pin Name Direction Description XCVR_#_RX2_N Input Receive data. Transceiver differential negative input. Each transceiver quad consists of four receive– signals. XCVR_#_RX1_N Input Receive data. Transceiver differential negative input. Each transceiver quad consists of four receive–...
Page 128: Design For Protocols
Board Design Recommendations Design for Protocols Transceiver designs are used in many high-speed protocols. Each protocol specifies the system requirements to meet the specific standards of the protocol. The electrical performance requirements for these protocols must be addressed by proper design of the PCB. The following sections describes the PCB requirements of RT PolarFire transceivers for specific protocols.
Page 129: Jesd204B
Board Design Recommendations Note: The ceramic 0201 and 0402 AC coupled capacitors are preferred for RT PolarFire FPGA transceivers. The transmitter must have AC coupling capacitors. 8.2.2 JESD204B JESD204B version increases the supported lane data rates to 12.5 Gbps and divides devices into three different speed grades.
Page 130: Unused Transceiver Pins
Board Design Recommendations 8.3.1 Unused Transceiver Pins If the transceiver interface is not used in the design, the transceiver pins must be connected as defined in the related PolarFire Package Pin Assignment Table (PPAT). Transceivers Insertion Loss The following table lists the type of insertion loss. Table 40 •...

Microchip Technology Microsemi UG0936 User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microchip Technology Microsemi UG0936

Summary of Contents for Microchip Technology Microsemi UG0936

Table of Contents
