Manufactured for Rooms To Go.
Step
Code
A
Allen Key 4 mm dia.
Allen Bolt 5/16" x 18 x 3"
1
Spring Washer 5/16" x 19 x 2mmT
B
Flat Washer 5/16" x 11 x 2mmT
Allen Bolt 5/16" x 18 x 3"
2
B
Spring Washer 5/16" x 19 x 2mmT
Flat Washer 5/16" x 11 x 2mmT
Allen Bolt 5/16" x 18 x 3"
3
B
Spring Washer 5/16" x 19 x 2mmT
Flat Washer 5/16" x 11 x 2mmT
HARDWARE PACK LOCATION(S):
PNWD
2290-GT CNT HGT TABLE
Assembly Instructions
PNWD
2290-GT CNT HGT TABLE
Hardware
PARTS LIST
Q'TY
1 Pc
8 Pcs
1. Table Top - 1 Pc
4 Pcs
2. Shelf - 2 Pcs
4 Pcs
3. Table Leg - 4 Pcs
SKU# 43222900
SKU# 43222900
PAGE 1OF2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO PNWD 2290-GT CNT HGT TABLE
Summary of Contents for ROOMS TO GO PNWD 2290-GT CNT HGT TABLE
- Page 1 Assembly Instructions Manufactured for Rooms To Go. PNWD 2290-GT CNT HGT TABLE SKU# 43222900 PARTS LIST Step Code Hardware Q’TY Allen Key 4 mm dia. 1 Pc Allen Bolt 5/16” x 18 x 3” 8 Pcs Spring Washer 5/16” x 19 x 2mmT 1.
- Page 2 Assembly Instructions Manufactured for Rooms To Go. PNWD 2290-GT CNT HGT TABLE SKU# 43222900 ***Cautions: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people are recommended in order to prevent personal injury and insure the parts are not damaged during the assembly.
