diLUSSO CE528MP Installation And Operation Manual

Undermount rangehood
Hide thumbs Also See for CE528MP:
Table of Contents

Advertisement

Quick Links

Download this manual
Undermount Rangehood
Installation and Operation Manual
To avoid the risk of accident or damage to the appliance, it is essential to read the
following instructions prior to product installation and / or first time usage.
CE528MP
CE728MP
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CE528MP and is the answer not in the manual?

Questions and answers

Related Manuals for diLUSSO CE528MP

Summary of Contents for diLUSSO CE528MP

  • Page 1 Undermount Rangehood CE528MP CE728MP Installation and Operation Manual To avoid the risk of accident or damage to the appliance, it is essential to read the following instructions prior to product installation and / or first time usage. V1.0...

  • Page 2: Table Of Contents

    CONTENTS Important Note ————–-———————————————————Page 3 Product Specification ———–——————————————————Page 6 Installation Instruction ——————–—-—————————————Page 8 Ducted mode ——————-————–—————————————Page 14 Recirculation mode ——–——————–-————————————-Page 16 Electrical Connection ———————————————–-—————Page 17 Rangehood Operation & Control ————————————————Page 18 Cleaning and Maintenance ———–——–-——————–-—————Page 19 Troubleshooting ———————–——-—————————————Page 21 Schematic Diagram——————————————————————Page 22...

  • Page 3: Important Note

    Important Notes Dear Customer Thank you for choosing our product. This appliance is easy to use; however please read this handbook carefully before installing and operating it. Herein, you will find the correct method of installation and tips for best use and maintenance of the product.
  • Page 4 Packaging cling film, polystyrene and plastic wrappings must be kept out of  reach of babies and young children to avoid suffocation. connect appliance there obvious signs  transportation damage. If the supply cord is damage, it must be replaced by the manufacturer, or its service agent as mentioned in Clause 7 (60335-2-31) Ensure the location in which this appliance is installed has good, permanent ...
  • Page 5 This appliance is not intended for use by person (including children) with  reduced physical, sensory or mental capabilities or lack of experience and knowledge. Unless, they have been given supervision or instruction regarding the use of appliance by personnel who is responsible for their safety. There is risk of catching fire if cleaning is not carried out in accordance with the ...

  • Page 6: Product Specification

    Product Specification CE528MP CE728MP Voltage / Frequency : 220-240Vac / 50Hz 220-240Vac / 50Hz Rated Power : 293 W 293 W Air Flow : 800m3/hr 800m3/hr Motor Power : 290W 290W Filter : Aluminium or Aluminium or Charcoal (Optional) Charcoal (Optional) Lighting : LED light 1.5W x 2...
  • Page 7 CE728MP Complete product comes with the following : 1 x rangehood body  1 x user manual & warranty card  Fixing screws ...

  • Page 8: Installation Instruction

    Installation Instruction Mount the rangehood to the bottom panel of a kitchen cabinet. The lower part of the hood must be located at a minimum height of 650mm above any cooker hob. The range hood installation shall comply with 650mm or the distance specified in the cooker hob instruction manual, whichever is higher.
  • Page 9 Cabinet cutout dimensions : Dimension Model CE528MP 497mm CE728MP 677mm...
  • Page 10 Installation Steps 1. Remove the metal filter. 2. Remove the stainless steel frame by unfastening 4 pcs of M4*10 screws.
  • Page 11 3. Unfastening ST4*10 of the terminal box, remove the lid of the terminal box, disconnect the control board wires. Disconnect the LED light wires. 4. Fix the rangehood to the cabinet cutout by using 12 pcs of ST4*18 screws.
  • Page 12 5. Put the stainless steel frame back into place and fasten the 4 pcs of M4*10 screws removed just now. 6. Reconnect the control board and LED lights wires in the terminal box. Close the terminal box lid and secure it with the ST4*10 screw.
  • Page 13 7. Put the metal filter back into place. 8. Install the 150mm duct pipe (optional)

  • Page 14: Ducted Mode

    Ducted mode (Vented mode) In the ducted mode, air is drawn into the hood. Oil is trapped in the aluminium filter while odours, fumes and condensation are then directed and vented to the outside. Only the aluminium filters is to be installed in the ducted mode. Ductwork should be planned carefully before drilling and cutting the duct.
  • Page 15 Note : Keep duct as straight as possible for maximum air flow and at least restrictions, while providing for easy maintenance. Vented system must be terminated to the outside. Ductwork can extend either through the wall or the roof. Do not terminate the vent system in an attic or other enclosed area.

  • Page 16: Recirculation Mode

    Recirculation mode In the recirculation mode, air is drawn into the hood. Oil is trapped in the aluminium filters while cooking odours is removed by the charcoal filter. Purified air then is directed back to the kitchen. In this mode, charcoal filter is strongly recommended to be fitted to the rangehood.

  • Page 17: Electrical Connection

    Electrical Connection Before connecting to the mains, make sure that : The electric meter, fuse, feeding line and socket are adequate to  withstand the maximum load required (refer to product data label for rated power) The supply system is regularly earthed, according to the regulations in force. ...

  • Page 18: Rangehood Operation & Control

    Rangehood Operation & Control The hood is equipped with a 3-speed control motor. Electronic control buttons are located at the front edge of the hood canopy. To achieve better results, it is recommended to switch the hood on 3 to 5 mins before cooking starts.

  • Page 19: Cleaning And Maintenance

    Cleaning & Maintenance Caution: Prior to cleaning or maintenance, always disconnect the power supply. Do not use a steam cleaner. To ensure the range hood is functioning effectively, regular maintenance is a must. Surfaces : Clean with warm soapy water and a soft sponge. Never use abrasive detergent, scouring pads, steel wool or solvents on any part of this appliance as this will cause irreparable damage.
  • Page 20 Charcoal Filter : Charcoal filter is not washable. To change the charcoal filter, first remove the metal filter, then loosen and remove the charcoal filter as indicated in diagram below. Get a pair of new charcoal filter and tighten them to fit to the side of extractor motor in the opposite direction.

  • Page 21: Troubleshooting

    Troubleshooting Scenario Possible Causes Solution Motor does not work No power supply Ensure the appliance is connected to mains properly Reset the circuit breaker Lights On, but motor Foreign object blocked the Contact the service agent does not work fan blade Capacitor or motor is Contact the service agent damaged...

  • Page 22: Schematic Diagram

    Schematic diagram AC INPUT Black(H) White Blue(M) Orange(L) Green Light...
  • Page 24 P/N:16173000A14545...
