- Page 2 INSTALLATION & OPERATING INSTRUCTIONS WARNING: RISK OF ELECTRIC SHOCK ONNECT ONLY TO A CIRCUIT PROTECTED BY A GROUND FAULT CIRCUIT INTERRUPTER HE UNIT SHOULD BE INSTALLED BY A QUALIFIED SERVICE REPRESENTATIVE LL ELECTRICAL WIRING OF THE MOTOR INSTALLATION MUST BE DONE BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH APPLICABLE ELECTRICAL CODES ROUNDING IS REQUIRED EFORE WORKING ON ANY...
- Page 3 WINTERIZATION To prevent damage during freezing conditions, disconnect all electrical power. Drain thoroughly and clean out any debris. Protect pump and motor from elements by covering or, if possible, store in a dry, well ventilated room. TROUBLESHOOTING MOTOR WILL NOT START: Check circuit breaker.
- Page 4 ASSEMBLY INSTRUCTION (Impeller & Seal Replacement) WARNING: RISK OF ELECTRIC SHOCK. EFORE PERFORMING ANY WORK ON THE PUMP UNIT BE CERTAIN THAT THE SOURCE OF ELECTRICAL POWER IS OFF AT THE MAIN JUNCTION BOX AND DISCONNECTED TO DISASSEMBLE PUMP CAUTION: DRAIN THE WATER FROM THE PLUMBING LINES BEFORE DISCONNECTING THE PUMP.
- Page 5 Removing the Seal Assemblies Remove seal rotating assembly from the impeller by carefully sliding it off of the impeller sleeve. Be sure not to scratch or damage the carbon disk surface if you are reusing this part. Remove the ceramic ring and rubber boot by knocking it out and/or prying it loose through the rear opening of the seal plate.
- Page 6 Reconnecting the Pump Unit 10. Clean the seals, gaskets, or o-rings of the plumbing connectors. Replace if cracked, worn, or damaged. 11. Reconnect the plumbing lines to the pump. Hand tighten only. 12. Be sure that the pump unit is secured properly to the platform or base, if applicable.
- Page 7 ® TUB-MASTER “TMCP2” PARTS LIST To Cross Reference: Refer to Diagram A Below. Ref. Description Motor Seal Plate, TMCP2 Series Seal Replacement, #200 Impeller, .50 HP Impeller, .75 HP O-ring, Volute, #158 Volute, TMCP2 Series Screw, #8-18 x 1" O-Ring, #226 Fitting, Tail Piece, 1-1/2"...
