SDI2HDMI-S
BOX
User Manual
Ver. 1.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDI2HDMI-S and is the answer not in the manual?

Questions and answers

Related Manuals for Yuan SDI2HDMI-S

Summary of Contents for Yuan SDI2HDMI-S

  • Page 1 SDI2HDMI-S User Manual Ver. 1.6...

  • Page 2: Table Of Contents

    Content Feature ................... 3 Front Panel ................4 Rear Panel ................4 Side Panel ................5 Installation ................6 Package Contents ............... 6 Button/LED Control ..............7 Specifications ................12 Firmware Upload ..............14 Update List ................16...

  • Page 3: Feature

    Feature  Supports HD format :  720p 50 & 60  1080i50 & 60  1080p24, 25, 30, 50 & 60  Support 525i & 625i SD D1 format  Auto 3G/HD/SD-SDI detection  Firmware is upgradable in the field using the integrated USB port ...

  • Page 4: Front Panel

    Front Panel Component Function From your SDI Display Device plug into SDI Output Port these ports ( Pass Through) From your HDMI Display Device plug into HDMI Output Port these ports Rear Panel Component Function Power Jack The Power adapter plug into here. LEDs indicate The LEDs is indicate Input/output Format MODE Button...

  • Page 5: Side Panel

    Side Panel Component Function USB Connector Upgrade Firmware/Control Box by PC...

  • Page 6: Installation

    Installation SDI2HD-S installation consists of the following: 1. Disconnect +12DC adaptor to converter. 2. Connect Video Source (SDI) to the BNCs Connector. 3. Connect HDMI equipment to the HDMI connector 4. Connect the +12DC adaptor to the converter. Package Contents The SDI2HD-S BOX package contains the following items: ...

  • Page 7: Button/Led Control

    Button/LED Control 1. Switch PC/AV Mode: Hold on the Button 2 until show the Output Mode OUTPUT MODE PC MODE a. PC mode: define output format is based on VESA ( PC) b. AV mode: define Output format is base on CEA861 (Customer) OSD Indicate LED indicate Power...
  • Page 8 2. Switch Format: a. AV Mode: If Pull the button 1, the box is setting to Output Format Mode and Frame number by button 2 and 3. By Pass 59.94i 720x480 59.94p 720x576 59.94p 1280x720 59.94i 1920x1080i 59.94p 1920x1080p 29.97p 23.97p : is default format at change button 1 after.
  • Page 9 b. PC Mode: Pull the button 1 and button 2, the box is setting to Output Format Mode in PC mode Button 1 Format Button 2 1920x1080 p60 1680x1050 p60 1600x1200 p60 1440x900 p60 1400x1050 p60 1366x768 p60 1280x1024 p60 1280x848 p60 1024x768 p60 800x600 p60...
  • Page 10 3. Aspect Ratio Mode: Pull the button 3 , the box will be seting to Aspect Ratio Mode Mode Display 16:9 (Default) (dot by dot)
  • Page 11 4. LED Mode: Resolution SD LED HD LED 3G LED Power LED ● ○ ○ ● NTSC / PAL 720p / 1080i / 1080 ○ ● ○ ● [24p,25p, 30p] ○ ○ ● ● 1080 [50p,60p] ○ ○ ○ ● No-Signal ●...

  • Page 12: Specifications

    Specifications DESCRIPTION SD – 720 x 480 i / 720 x 576 i HD– 1280 x 720 24p/23.97p/25p/30p/29.97p 1280 x 720 50p/60p/59.94p Support Video Resolution 1920 x 1080 50i/60i/59.94i 1920 x 1080 24p/23.97p/25p/30p/29.97p 3G– 1920 x 1080 50p/60p/59.94p CEA861: 720x480 60i/60p/59.94i/59.97p 720x576 50i/50p 1280x720 50p/60p/59.94p 1920x1080 50i/60i/59.94i...
  • Page 13 Button Format Switch/TV wall Housing SECC Dimension L:104mm x W:63.3mm xH:26mm Power Source Power Adapter: AC 100 ~ 240 V/DC (+6 ~ 15 V) 0~50°C[32~114°F] Operation Temperature -20~+60°C Storage Temperature...

  • Page 14: Firmware Upload

    Firmware Upload  Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”)
  • Page 15 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. PASS message will appear when the procedures finished.

  • Page 16: Update List

    Update List Data Version Command 2013.03.04 V1.4 1. Release 2013.11.29 V1.5 1. Add Aspect Ratio Mode 2015.03.20 V1.6 1. Change Box Pic...
