- Page 1 HD2HD-4KS User Manual Ver. 1.0...
-
Page 2: Table Of Contents
Content Feature ................... 3 Front Panel ................4 Rear Panel ................4 DipSwitch/LED Control ..............5 Installation ................11 Package Contents ..............11 Specifications ................12 Firmware Upload ..............13 Update List ................15... -
Page 3: Feature
Feature Supports HD formats : 720p50 & 60 1080i50 & 60 1080p24, 25, 30, 50 & 60 Support 525i & 625i SD D1 format Auto Format detection Frame rate conversion(1.000/1.001) External Dipswitch Configuration ... -
Page 4: Front Panel
Front Panel Component Function From your HDMI Display Device plug into HDMI Output Port these ports The LEDs is indicate Output Format LEDs indicate (USB/DIP/HDCP/POWER) From your HDMI Device plug into these HDMI Input Port ports Mode Switch Setting Configuration for Box Rear Panel Component Function... -
Page 5: Dipswitch/Led Control
DipSwitch/LED Control Component Function Control interface Control by Dipswitch or USB Audio Mute Audio Mute or Un-Mute UHD Control Select UHD or HD Output format Output Format of Index Frame Rate Select frame Rate(1000/1001) Contorl Interface: Select contorl interface by USb or Dipswitch. Control interface Dipswitch Indicates Dipswitch... - Page 6 Audio Mute Select Audio Mute or Un-Mute. Audio Mute Dipswitch Indicates Un-Mute Mute UHD(2160p) contorl Select UHD or HD UHD Control Dipswitch Indicates Disable Enable...
- Page 7 Output Format: Select ouput format (UHD disable) Resolution Dipswitch Indicates Resolution 1920x1080p60 1280x720p50 1920x1080p50 720x480p60 1920x1080p30 720x576p50 1920x1080p25 720x480i59 1920x1080p24 720x576i50 1920x1080i60 1920x1080i50 1280x720p60...
- Page 8 UHD Enable: Resolution Dipswitch Indicates Resolution 3840x2160p60 1280x720p50 3840x2160p50 720x480p60 3840x2160p30 720x576p50 3840x2160p25 720x480i59 3840x2160p24 720x576i50 1920x1080i60 1920x1080i50 1280x720p60...
- Page 9 Frame Rate contorl Select output frame (1000/1001 ) Frame Rate Dipswitch Indicates 1000 1001 Resolution Dipswitch Indicates Resolution 1920x1080p59 1280x720p50 3840x2160p59 3840x2160p50 720x480p59 1920x1080p29 720x576p50 3840x2160p29 3840x2160p25 720x480i59 1920x1080p23 720x576i50 3840x2160p23 1920x1080i59 1920x1080i50 1280x720p59 If Ouptut foramt is 1920x1080p60 and Frame rate control is 1001, so current output format is 1920x1080p59.94...
- Page 10 Pattern Genertor Mode: (USB control) input signal is plug out, the Box auto change to Pattern Genertor mode. It is proivded the 13 of Mode...
-
Page 11: Installation
2. Connect Video Source (HDMI) to the HDMI Connector. 3. Connect SDI Equipment to the BNCs connector 4. Connect the +12DC adaptor to the converter. Package Contents The HD2HD-4KS package contains the following items: User Manual x 1 ... -
Page 12: Specifications
Specifications DESCRIPTION HDMI Format CEA/VESA Audio Support Up to 8 channel, Audio Sample Up to 192KHz Firmware Updates Via Mini-USB Input 1 x HDMI Output 1 x HDMI HDMI Connector TYPE A [19-pin female] USB Connector Mini-USB Dipswitch Control interface/Audio/UHD/Output format/frame rate Housing SECC Dimension... -
Page 13: Firmware Upload
Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”) - Page 14 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. The PASS message will appear when the procedures finished.
-
Page 15: Update List
Update List Data Version Command 2016.07.25 V1.0 1. Release...
