Front Panel Component Function SDI Input Port From your SDI Device plug into this port SDI Pass Thru From your SDI Display Device plug into this ports HDMI Input Port From your HDMI Device plug into this port Input Port/ Ouptut The LEDs are indicate Input Ports and Ouptut Port LED Source...
Side Panel Component Function USB Port Upgrade firmware/Control Box From PC DipSwitch/LED Control Component Function Control Mode Control Box from Dipswitch or USB Input Source Select Input Source Output Source Select Output Source Output Format Select Output Format Frame Rate Select 1000 or 1001 Frame rate...
Page 6
Control Mode: Control Box from Dipswitch or USB. Control Mode Dipswitch Indicates DipSwitch Input Source: Select Input Source from SDI or HDMI Input Source Dipswitch Indicates HDMI...
Page 9
Frame Rate: Select Frame Rate 1000 or 1001 Output Source Dipswitch Indicates 1000 1001 LED Indicate: 2 3 4 5 Component Function SDI Input The LED is indicate SDI Signal Status HDMI Input The LED is indicate HDMI Signal status DVI-D(HDMI) The LED is indicate DVI-D(HDMI) Signal Output...
Installation SDI2MULTI installation consists of the following: 1. Disconnect +12DC adaptor to converter. 2. Connect Video Source to the Input Connector. 3. Connect Display Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. Package Contents The SDI2MULTI package contains the following items: ...
Specifications SDI2MULTI DESCRIPTION SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 10485Gb/s and 270Mb/s Audio Support 8 - Channel RG6/RG59(75Ω ) Coaxial Cable Type 3G: 100m of RG6/ 86m of RG59 HD: 170m of RG6/ 120m of RG59 SD: 400m of RG6/ 280m of RG59 Cable Equalization...
Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”)
Page 15
Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. The PASS message will appear when the procedures finished.
