Yuan SDI2SDIS User Manual

Sdi to sdi up/down converter with genlock
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SDI2SDIS
User Manual
Rev1.1

Advertisement

Table of Contents
loading

Related Manuals for Yuan SDI2SDIS

Summary of Contents for Yuan SDI2SDIS

  • Page 1 SDI2SDIS User Manual Rev1.1...

  • Page 2: Table Of Contents

    Content Feature ..................3 Front Panel ................4 Rear Panel ................4 DipSwitch/LED Control ..............5 Genlock Mode ................8 Installation ................9 Package Contents ................ 9 Specifications ................10 Firmware Upload ..............11 Update List ................13...

  • Page 3: Feature

    Feature  SDI Supports HD formats :  720p50 & 60  1080i50 & 60  1080p24, 25, 30, 50 & 60  SDI Support 525i & 625i SD D1 format  SDI support RGB/YUV 4:4:4 Sampled  Auto 3G/HD/SD-SDI detection ...

  • Page 4: Front Panel

    Front Panel Component Function SDI Output port (Up/Down From your SDI Display Device plug into this ports Conversion) Indicate Box LED The LEDs are indicate Box configuration Dipswitch Setting configuration for Box Power Jack The Power adapter plug into here. Rear Panel 1 2 3 Component...

  • Page 5: Dipswitch/Led Control

    DipSwitch/LED Control Component Function Control Mode Control Box from Dipswitch or USB Genlock Mode Select Genlock Source(Free/SDI/Ref) Aspect Ratio Select Aspect Ratio Output Format Select Output Format  Control Mode: Control Box from Dipswitch or USB. Control Mode Dipswitch Indicates DipSwitch ...
  • Page 6  Output Source: Select Output Aspect Ratio Output Source Dipswitch Indicates Full Screen 16:9 Dot by dot...
  • Page 7  Output Format: Resolution Dipswitch Indicates Resolution 1920x1080p60 1920x1080i60 1920x1080i59 1920x1080p59 1920x1080i50 1920x1080p50 1920x1080p30 1280x720p60 1920x1080p29 1280x720p59 1920x1080p25 1280x720p50 1920x1080p24 720x480i59 1920x1080p23 720x576i50...

  • Page 8: Genlock Mode

    Genlock Mode 480i 576i 1080 1080 1080 1080 1080 1080 480i ● ● ● ● ● 576i ● ● ● ● 720p ● 720p ● 720p ● 1080i ● ● ● ● 1080i ● ● ● ● ● 1080i ● ●...

  • Page 9: Installation

    2. Connect Video Source to the Input Connector. 3. Connect Display Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. Package Contents The SDI2SDIS package contains the following items:  User Manual x 1  +12 DC Adapter x 1 ...

  • Page 10: Specifications

    Specifications DESCRIPTION SDI2SDI-S SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 1.485Gb/s and 270Mb/s Audio Support Up to 8 channel. RG6/RG59(75Ω) Coaxial Cable Type 3G: 100m of RG6/ 86m of RG59 HD: 170m of RG6/ 120m of RG59 SD: 400m of RG6/ 280m of RG59 Cable Equalization...

  • Page 11: Firmware Upload

    Firmware Upload  Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”)
  • Page 12 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. PASS message will appear when the procedures finished.

  • Page 13: Update List

    Update List Data Version Command 2014.09.22 V1.0 1. Release 2015.07.13 V1.1 1. Modify SDI2SDI Pic...
