- Page 1 HD2SDIS-EA User Manual Rev1.1...
-
Page 2: Table Of Contents
Content Feature ................... 3 Front Panel ................4 Rear Panel ................4 DipSwitch/LED Control ..............5 Installation ................10 Package Contents ..............10 Specifications ................11 Firmware Upload ..............12 Appendix Table A ..............14 Update List ................15... -
Page 3: Feature
Feature SDI Supports HD formats : 720p50 & 60 1080i50 & 60 1080p24, 25, 30, 50 & 60 SDI Support 525i & 625i SD D1 format Auto 3G/HD/SD-SDI detection Can be split one 3G-SDI displays simultaneously. ... -
Page 4: Front Panel
Front Panel Component Function L/R Audio/ SPDIF From your Audio Device plug into this port input Port Balance Audio(XLR)/AES input From your XLR Audio Device plug into this port Port HDMI Input Port From your HDMI Device plug into this port Rear Panel Component Function... -
Page 5: Dipswitch/Led Control
DipSwitch/LED Control Component Function Dipswitch/UBS Indicate the Main control from USB or Control Dipswitch Audio Source five of kinds Audio input source Output format Control Box to switch Output Format. Main Control : Box can be select main control by USB or Dipswitch. Resolution Dipswitch Indicates Dipswitch (Default) - Page 6 Output Format: DAC-70 can be select 16 of kinds output format. Resolution Dipswitch Indicates Resolution Dipswitch Indicates 1920x1080p60 1920x1080i60 1920x1080p59 1920x1080i59 1920x1080p50 1920x1080i50 1920x1080p30 1280x720p60 1920x1080p29 1280x720p59 1920x1080p25 1280x720p50 1920x1080p24 720x480i59 1920x1080p23 720x576i50 LED Indicate: POWER/SIGNAL Resolution SD LED HD LED 3G LED ●...
- Page 7 Input Audio Source: Box can choose one of Five standard input audio Source by DipSwitch. Input Source Dipswitch Indicates Embedded L/R Audio Balance Audio (XLR) SPDIF a. Embedded Audio Component Description From you HDMI Source(include the audio) HDMI Audio plug into this port...
- Page 8 b. L/R Audio Component Description Left audio From stereo of Left audio plug into this port Right audio From stereo of Right audio plug into this port c. XLR Audio Component Description Left XLR Audio From XLR of Left audio plug into this port Right XLR Audio From XLR of Right audio plug into this port Support two input impedance and four output level.
- Page 9 d. SPDIF Audio Component Description SPDIF audio From SPDIF audio plug into this port e. AES-3 audio Component Description AES-3 audio From AES audio plug into this port...
-
Page 10: Installation
2. Connect Video Source to the Input Connector. 3. Connect Display Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. Package Contents The HD2SDIS-EA package contains the following items: User Manual x 1 +12 DC Adapter x 1 ... -
Page 11: Specifications
Specifications DESCRIPTION VPC-HS2EA SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 10485Gb/s and 270Mb/s Stereo two channel (RCA) Balance audio 2 channel (XLR) Audio Support SPDIF AES-3 Re-Sample Clock Auto Resample audio clock to 48Khz RG6/RG59(75Ω) Coaxial Cable Type 3G: 100m of RG6/ 86m of RG59 HD: 170m of RG6/... -
Page 12: Firmware Upload
Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”) - Page 13 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. The PASS message will appear when the procedures finished.
-
Page 14: Appendix Table A
Appendix Table A Support CEA-861/VESA Format 720x480i60 720x576i50 720x480 p60 720x576 p50 1280x720p60 1280x720p50 1920x1080i60 1920x1080i50 1920x1080p24 1920x1080p25 1920x1080p30 1920x1080p60 1920x1080p50 640x350p85 640x400p85 720x400p85 640x480p60 640x480p72 640x480p75 640x480p85 800x600p56 800x600p60 800x600p72 800x600p75 800x600p85 848x480p60 1024x768p50 1024x768p59 1024x768p60 1024x768p70 1024x768p75 1024x768p85 1152x864p70 1152x864p75... -
Page 15: Update List
Update List Data Version Command 2014.05.07 V1.0 1. Release 2015/03.20 V1.1 1. Change Box Pic...
