- Page 1 Isotemp Flammable Materials Storage Refrigerator Model 13-986-450R 104519 Rev.B...
-
Page 2: Table Of Contents
Table of Contents Safety Information ..............................3 Alert Signals..............................3 Unpacking ................................4 Visible Loss or Damage..........................4 Concealed Loss or Damage ........................4 Performance Characteristics ..........................5 Temperature Ranges ............................5 Electrical Requirements..........................5 Installation ................................6 Selecting a Location ............................6 Leveling The Unit ............................6 Isotemp Shelves ................................6 Install External probe in Thermowell ......................7 Electrical Connection ...................... -
Page 3: Safety Information
Safety Information Your satisfaction and safety are important to Fisher Scientific and a complete understanding of this unit is necessary to attain these objectives. As the ultimate user of this apparatus, it is your responsibility to understand its proper function and operational characteristics. -
Page 4: Unpacking
Unpacking Save all packing material if apparatus is received dam- aged. This merchandise was carefully packed and thor- oughly inspected before leaving our factory. Responsibility for its safe delivery was assumed by the carrier upon acceptance of the shipment; therefore, claims for loss or damage sustained in transit must be made upon the carrier by the recipient as follows: Visible Loss or Damage... -
Page 5: Performance Characteristics
Performance Characteristics Temperature Ranges 1° to 12°C (34° to 53.6°F) Electrical Requirements 115 Volts ±10%, 60 Hz, 9.1 Amps... -
Page 6: Installation
Installation S electing a Location Choose a location for the refrigerator that will provide at least three inches of clearance between the cabinet and any adjacent vertical surface at the sides and rear. Twelve inches of clearance is required above the grille. Appropriate electrical power must be available. -
Page 7: Install External Probe In Thermowell
NSTALLATION Thermowell for adding external monitoring device Install External probe in Thermowell An external temperature monitoring device can be added to the thermowell beside the display thermowell mounted on top of the unit. See Figure 2 for location of the thermowell. The size of the sensor must be less than 0.3 diameter to fit inside the thermowell. -
Page 8: Electrical Connection
NSTALLATION Electrical Connection Caution Determine the total amount of current presently being Be sure that the power supply is the used by other apparatus connected to the circuit that will same voltage that is specified on the be used by this refrigerator. It is critical that this added refrigerator’s data plate. -
Page 9: Operation
3000 ft., have the thermostat adjusted by a techni- cian. See photo below . Temperature Display Interior temperature is indicated in degrees C by the solar powered LCD display mounted in the header panel. Temperature Adjustment Instructions- Model 13-986-450R FMS Refrigerator... -
Page 10: Material Compatibility
PERATION Material Compatibility The interior cabinet of this unit is constructed of anodized aluminum. Care must be exercised when determining which chemicals may be stored in the refrigerator and freezer sections and which type of storage materials should be employed. ABS Plastic deteriorates when exposed to, but not limited to, the following: Aliphatic Hydrocarbons;... -
Page 11: Troubleshooting
Troubleshooting This table is intended to assist in resolving user-correctable Refrigerator problems by relating symptoms to their likely causes. If service beyond the scope of this table is required, contact Customer Service at 1-800-438-4851. Symptom Action Probable Cause Does Not Run Unit Unplugged Plug in Unit Blown fuse or tripped... -
Page 12: Maintenance
Maintenance Cabinet Cleaning Warning The cabinet interior should be cleaned frequently. Any When servicing the unit, disconnect spilled liquid should be wiped off immediately. Stains from the electrical power source. resulting from some spills can be permanent if not quickly removed. -
Page 13: Warranty
Warranty Laboratory instruments and equipment manufactured by Fisher Scientific Company L.L.C. – Laboratory Equipment Division (hereinafter called “the Company”) are warranted only as stated below. Subject to the exceptions and upon the conditions specified below, the Company agrees, at its election, to...
