- Page 2 Copyright notation © 2012 Nanjing IOT Sensor Technology Co., Ltd All Rights Reserved. Wulian， is the trademark and registered trade mark of Nanjing IOT Sensor Technology Co., Ltd. The other products mentioned in this article or company names may be the trademark or trade name of their respective owners.
- Page 3 Wireless Wall Touch Switch User Manual When using, if the practical situation of the product is different with that in the manual, or if you want to get more information, or you have any questions or ideas, please contact us as below: Ⅰ...
- Page 4 Wireless Wall Touch Switch User Manual Ⅱ .Function features Support ZigBee HA protocol ZigBee device type：Router Compliant with ergonomic design Fashionable yet refined appearance Simple and flexible operation Easy to install Multiple colors available, perfectly paired with different home style Ⅲ...
- Page 5 Wireless Wall Touch Switch User Manual Multifunction Key LED Indicator 1 - way Multifunction Key LED Indicator 2 - way...
- Page 6 Wireless Wall Touch Switch User Manual Multifunction Key LED Indicator 3-way...
- Page 7 Wireless Wall Touch Switch User Manual Multifunction key LED Indicator 4 - way Ⅳ .Installation steps Connect this product with the wire of the wall box; 1-way 2-way 3-way 4-way...
- Page 8 Wireless Wall Touch Switch User Manual Protect the earth 1-way 1-way 1-way Load 1-way Load Load Output Load Output Output Output 2-way 2-way Load 2-way Load ∕ Output Load Output Output 3-way Load 3-way ∕ ∕ Output Load Output 4-way ∕...
- Page 9 Wireless Wall Touch Switch User Manual Live Line Input Note: Please make sure that the power has been turned off before installation! Dangerous, non-professionals are prohibited operating without authorization. Fasten the base of this product inside the wall box with 2 screws, same installation method with the ordinary wall switch;...
- Page 10 Wireless Wall Touch Switch User Manual...
- Page 11 Wireless Wall Touch Switch User Manual Ⅴ .Application methods 1. Networking Setup It can be used as an ordinary wall switch, or used together with communication gateway; Quickly click 【 multi-function key 】 4 times to join ZigBee network. LED indicator flashes when it is searching the network;...
- Page 12 Wireless Wall Touch Switch User Manual shall be within 1s. LED indicator goes out 2 seconds later when joining ZigBee network succeeds. Quickly click each key 3 times in turn and send binding request of each way (this function is optional); The single click time...
- Page 13 Wireless Wall Touch Switch User Manual shall be within 1s. If the binding succeeds, LED indicator flashes 3 times. If it fails, LED indicator flashes 6 times. Long press 【multi-function key】for 10 seconds to restore to factory settings. Factory reset is not to join ZigBee network by...
- Page 14 2. Software Download (1) Choose the related software according to different smart mobile terminal: a) Android users please search “wulian” in “Google Play Store", selecting “Smart Home” for downloading; b) iPhone users please come to “APP Store” to search “smart...
- Page 15 Wireless Wall Touch Switch User Manual c) Pad users can directly log on our official website http://www.wulian.cc for downloading. (2) Install and operate according to the indication of each version of software; (3) Installation completed, enter setup and usage interface;...
- Page 16 Wireless Wall Touch Switch User Manual in case of load short circuit, and it goes out in case of load access. Ⅵ .Notes Installation If you are new to using it, please read this product instruction carefully before installation. Cleaning This product should be installed in a clean and dry place to avoid humidity or other material entering internal components which will influence its work.
- Page 17 Wireless Wall Touch Switch User Manual of pile should be no more than 10 layers. Store temperature should be between -10℃ ～ + 40 ℃ with humidity ≤75%. Transportation Those products packed in boxes can be transported with any kind of means, if the direct influence of rain, snow, and severe impact is avoided.
- Page 18 Wireless Wall Touch Switch User Manual Multiple pictures and colors available Color Ⅷ .Contents within the package Components Quantity Wireless Wall Touch Switch Decorative Cover Instruction Screw(s)
- Page 19 Wireless Wall Touch Switch User Manual Ⅸ .Ordering information Product(s) Art. No. Model 1-way WLPN1206301 WL-SFB-C01 2-way WLPN1206302 WL-SFB-C02 3-way WLPN1206303 WL-SFB-C03 4-way WLPN1206304 WL-SFB-C04 138×118×68mm Packing Size 110V-230V Power Supply...
- Page 20 Wireless Wall Touch Switch User Manual Resistive Load: 600 W per way Type of Workload Inductive/ Capacitive load: 350 W per way...
