- Page 2 Copyright notation © 2012 Nanjing IOT Sensor Technology Co., Ltd All Rights Reserved. Wulian， is the trademark and registered trade mark of Nanjing IOT Sensor Technology Co., Ltd. The other products mentioned in this article or company names may be the trademark or trade name of their respective owners.
-
Page 3: Product Introduction
Wireless Scene Switch series User Manual When using, if the practical situation of the product is different with that in the manual, or if you want to get more information, or you have any questions or ideas, please contact us as below: Ⅰ... -
Page 4: Function Features
Wireless Scene Switch series User Manual are tho usands of miles away from home. ( This brochure takes quadruple - way for example ) This series of products are widely used in smart home, smart hotel, and smart building etc by means of its unique professional performance. -
Page 5: Function Diagram
Wireless Scene Switch series User Manual Wireless design to decrease renovation costs. Ⅲ .Function Diagram... - Page 6 Wireless Scene Switch series User Manual Multi - functional Key LED Indicator Two - way Multi - functional Key LED Indicator T hree - way...
-
Page 7: Installation Steps
Wireless Scene Switch series User Manual Multi - functional Key LED Indicator Four - way Ⅳ .Installation Steps 1. Connect this product with the wire of the wall box;... - Page 8 Wireless Scene Switch series User Manual Protect the earth Null line input Live line input Note: Please make sure that the power has been turned off before installation! Dangerous, non-professionals are prohibited operating without authorization. 2. Fasten the base of this product inside the wall box with 2 screws, same installation method with the ordinary wall switch;...
- Page 9 Wireless Scene Switch series User Manual...
- Page 10 Wireless Scene Switch series User Manual Ⅴ .Application Method 1. Networking setup (1) It can be used with communication gateway together; (2) Quickly click【multi-function key】4 times to join ZigBee network. LED indicator flashes when it is searching the network; The single click time...
- Page 11 Wireless Scene Switch series User Manual shall be within 1s. LED indicator goes out 2 seconds later when joining ZigBee network succeeds. (3) Press【multi-function key】for 10 seconds to restore to factory...
- Page 12 Wireless Scene Switch series User Manual settings. LED indicator goes out after flashing for 4 times. (Factory reset is not to join ZigBee Network by default)
- Page 13 2．Software Download (1) Choose the related software according to different smart mobile terminal: a) Android users please search “wulian” in “Google Play Store", selecting “Smart Home” for downloading; b) iPhone users please come to “APP Store” to search “smart home”, selecting “smart home” for downloading;...
- Page 14 Wireless Scene Switch series User Manual (4) It also supports computer operation according to users’ needs. 3. How to use Users can control the switch with ease via mobile terminal device and choose any scene mode. Specific operational processes see various versions of instructions.
- Page 15 Wireless Scene Switch series User Manual influence its work. When the surface is stained with dust, dry it with soft cloth, cleaning fluid with corrosive composition and other chemical solvent are forbidden. Storage Those products packed in boxes should be placed in the location which is dry, free of corrosive gas and available to air.
-
Page 16: Product Specification
Wireless Scene Switch series User Manual Ⅶ . Product Specification IEEE802.15.4 (ZigBee) Communication Mode 100m (Visible) Communication Distance 250g Weight Net Weight 150g Multiple pictures and colors Color available Ⅷ . Contents within the package... -
Page 17: Ordering Information
Wireless Scene Switch series User Manual Components Quantity Wireless Scene Switch Decorative Cover Instruction Screw Ⅸ .Ordering Information Product(s) Art.No. Model Double-way WLPN1209072 WL-SLB-E02... - Page 18 Wireless Scene Switch series User Manual Triple-way WLPN1209073 WL-SLB-E03 Quadruple-way WLPN1209074 WL-SLB-E04 138×118×68mm Packing Size 110V-230V Power...
