- Page 2 Copyright notation © 2012 Nanjing IOT Sensor Technology Co., Ltd All Rights Reserved. Wulian， is the trademark and registered trade mark of Nanjing IOT Sensor Technology Co., Ltd. The other products mentioned in this article or company names may be the trademark or trade name of their respective owners.
- Page 3 Wireless Touch Dimmer Switch series User Manual When using, if the practical situation of the product is different with that in the manual, or if you want to get more information, or you have any questions or ideas, please contact us as below: Ⅰ...
- Page 4 Wireless Touch Dimmer Switch series User Manual breeding etc. （ This brochure takes 2 - way touch dimmer switch for example ） Ⅱ . Function features Support Zigbee HA protocol ZigBee device type：Router Trendy yet delicate appearance Simple installation and flexible operation Customized according to individual preferences...
- Page 5 Wireless Touch Dimmer Switch series User Manual Ⅲ . Function illustration...
- Page 6 Wireless Touch Dimmer Switch series User Manual Multifunction Key LED Indicator Multifunction Key LED Indicator...
- Page 7 Wireless Touch Dimmer Switch series User Manual Ⅳ . Installation steps 1. Connect this product with the wire of the wall box; 1-way 2-way Protect the earth 1-way output load 1-way output load ∕ 2-way output load Null Line Input Live Line Input...
- Page 8 Wireless Touch Dimmer Switch series User Manual Note: Please make sure that the power has been turned off before installation! Dangerous, non-professionals are prohibited operating without authorization. 2. Fasten the base of this product inside the wall box with 2 screws, same installation method with the ordinary wall switch;...
- Page 9 Wireless Touch Dimmer Switch series User Manual...
- Page 10 Wireless Touch Dimmer Switch series User Manual Ⅴ . Application methods 1. Networking Setup (1) It can be used just as an ordinary switch, or matched with communication gateway; (2) Quickly click 【 multi-function key 】 4 times to join ZigBee network.
- Page 11 Wireless Touch Dimmer Switch series User Manual shall be within 1s. LED indicator goes out 2 seconds later when joining ZigBee n etwork succeeds. (3) Long press 【multi-function key】for 10 seconds to restore to...
- Page 12 ． Software download (1) Choose the related software according to different smart mobile terminal: Android users please search “wulian” in “Google Play Store", selecting “Smart Home” for downloading; iPhone users please come to “APP Store” to search “smart home”, selecting “smart home” for downloading;...
- Page 13 Wireless Touch Dimmer Switch series User Manual Pad users can directly log on our official website http://www.wulian.cc for downloading. (2) Install and operate according to the indication of each version of software; (3) Installation completed, enter setup and usage interface;...
- Page 14 Wireless Touch Dimmer Switch series User Manual If you are new to using it, please read this product instruction carefully before installation. Cleaning This product should be installed in a clean and dry place to avoid humidity or other material entering internal components which will influence its work.
- Page 15 Wireless Touch Dimmer Switch series User Manual Those products packed in boxes can be transported with any kind of means, if the direct influence of rain, snow, and severe impact is avoided. About after-sale service Once broken, it should be send to the local maintenance station and only professional personnel can open it.
- Page 16 Wireless Touch Dimmer Switch series User Manual 200g Net Weight Multiple pictures and Colors Color available Ⅷ . Contents within the package Components Quantity Wireless Touch Dimmer Switch Decorative Cover Instruction...
- Page 17 Wireless Touch Dimmer Switch series User Manual Screw Ⅸ . Ordering information Product(s) Art.No. Model 1-way Switch WLPN1209101 WL-DS-C01 2-way Switch WLPN1209102 WL-DS-C02 Packing Size 138×118×68mm...
- Page 18 Wireless Touch Dimmer Switch series User Manual Power Input 110V-250V Resistive Load: 300W per way Type of Workload...
