EDGE 50 LE
OWNERS MANUAL
Sc.NZ.ED50 Version 1.2 26/11/18
Contents of manual may be updated without notice.
For the latest version of this manual please refer to our website: www.scandiastoves.com.au
Edge 50LE
Scandia Heating (Aust) Pty Ltd
Head Office
58-62 Access Way
Carrum Downs VIC 3201
Australia
+61 3 8579 5900
info@scandiastoves.com.au
www.scandiastoves.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the EDGE 50 LE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for scandia EDGE 50 LE

Summary of Contents for scandia EDGE 50 LE

  • Page 1 EDGE 50 LE OWNERS MANUAL Edge 50LE Scandia Heating (Aust) Pty Ltd Head Office 58-62 Access Way Carrum Downs VIC 3201 Australia +61 3 8579 5900 Sc.NZ.ED50 Version 1.2 26/11/18 info@scandiastoves.com.au Contents of manual may be updated without notice. www.scandiastoves.com.au...

  • Page 3: Table Of Contents

    Exploded diagram / Spare parts list INTRODUCTION Congratulations on purchasing a genuine Scandia Wood heater. When cared for properly, these high quality, finely crafted wood heaters will offer many years of reliable performance. This instruction manual has been developed to ensure optimum performance from your Scandia wood heater. It’s very important that you thoroughly read and understand all instructions before using your new wood heater.

  • Page 4: Wood Heater Safety

    WOOD HEATER SAFETY When properly maintained and operated your wood heater should give you many years of service, however there are important safety aspects of these products that you need to be aware of when operating a wood heater. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 5: Before Installing Your Wood Heater

    The floor protector must consist of 9mm thick cement fibre sheet which has a thermal resistance of 0.008m2 K/W, per 9mm thickness or equivalent. Scandia have a complete range of suitable ready to install hearth pads for straight wall and corner installations.

  • Page 6: Installation

    *When using Scandia decorative mesh flue kit. (Decorative flue is fitted with an additional heat shield) When using Scandia Sleek Black / Graphite flue kit. (Sleek black / Graphite flue is fitted with an additional heat shield) Manufacturers recommendation: Keep all combustible materials at least 1.22 metres (4 feet) away from the appliance.
  • Page 7 Australian/New Zealand standards (AS/NZS 2918:2018) & manufacturers recommendations. Scandia wood heaters are independently tested to New Zealand Standards using a Scandia flue kit, we always recommend using a Scandia flue kit when installing a Scandia wood fire.
  • Page 8 INSTALLATION ..continued Position the drop box between the angle brackets, keeping a 25mm clearance to combustibles. The located end of the drop box must protrude no less than 150mm down from the ceiling or any combustible material. Fix the drop box to the angle brackets.
  • Page 9 MINIMUM INSTALLATION CLEARANCES FIGURE 1 Increase flue length as necessary until nothing within 6m of flue top ANY NEARBY STRUCTURE FIGURE 2...
  • Page 10 INSTALLATION ..continued FIREBOX ASSEMBLY: Remove all loose items from the fire box. First install the rear vermiculite liners. Disconnect air tube by removing the locking pin from locating lug positioned in the top RHS of the firebox, slide air tube to right and lower allowing it to hang supporting itself. (The air tube cannot be removed completely). Insert top baffle and lift air tube, positioning it on the locating lug, replace locking pin.

  • Page 11: Operating Your Wood Heater

    OPERATING YOUR WOOD HEATER CONTROLS AND THEIR USE Air Slide to control primary air intake CLOSED OPEN Latch to open door PLEASE USE GLOVES PROVIDED TO OPEN / CLOSE DOOR FUEL Your wood heater is designed to burn dry softwood only. It is NOT designed to burn the following: •...
  • Page 12 AIR CONTROLS Your wood heater needs air to burn the fuel. Scandia wood heaters draw air from multiple areas to maximize efficiency. The air is supplied through an adjustable primary air slide at the upper rear left side of the wood heater and secondary non-adjustable air through the rear of the firebox and air-tube.

  • Page 13: Wood Heater Maintenance

    WOOD HEATER MAINTENANCE CHECK YOUR WOOD HEATER REGULARLY Initially, we recommend you check your flue system at least once per month. After the first few months you will notice a pattern of soot and creosote build up and you can then determine an inspection interval for checking soot and creosote build up that is suitable for your wood heater installation.
  • Page 14 There may be times however when you need to clean the glass. To do this, use a soft cloth and a non-abrasive glass cleaner. Only ever clean the glass when the wood heater is cold. For best results select from Scandia’s range of glass cleaning products.

  • Page 15: Trouble Shooting

    TROUBLE SHOOTING Many people under estimate the importance of using a professional installer with experience in wood heating who adheres to New Zealand Standards to install their wood fire. If you are having issues with your wood fire not working the way you think it should, we implore you to speak to your installer first; they can help you with issues such as burning too much or too little wood, smoke in the room when you open the door, blackened glass or build-up of creosote during use.

  • Page 16: Warranty

    WARRANTY SCANDIA LIMITED WARRANTY This limited warranty is given by Scandia Heating (Aust) Pty Ltd (ACN 005 868 093) (Scandia or we) to the original retail purchaser (you) of the wood heater to which this Warranty applies. Our goods come with guarantees that cannot be excluded under the New Zealand Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
  • Page 17 (including labour costs). Scandia will only be responsible for transport of the wood heater from the original place of purchase to Scandia’s premises (and back), and replacement or repair in accordance with this Warranty.
  • Page 18 EDGE 50 SPARE PARTS LIST LEGEND PART SCANDIA PART NO. Body weldment SPE5001 SPE5002LE Upper decorative grill SPE5003 Rear heat shield SPE5004 Side vermiculite SPE5005 Bottom vermiculite SPE5006 Rear vermiculite SPE5007 Top vermiculite SPE5008 Door frame SPE5009 Door glass SPE5010...
  • Page 19 Head Office Scandia Heating (Aust) Pty Ltd 58 Access Way, (03) 8579 5900 Carrum Downs VIC 3201 info@scandiastoves.com.au Australia www.scandiastoves.com.au...
