Summary of Contents for MASINGO Illuminato Q4
-
Page 8: Side Views
Side Views... - Page 11 Check the machine for Clean and store the machine damage before each use. after each use. Do not expose this product Do not use the machine with to water, moisture, heat, or attachments not approved steam. Do not place objects by the manufacturer.
- Page 12 Charge the machine and insert two AA batteries into each microphone. Power on the machine, projector, and microphones. Focus the projector on a wall or screen. Connect to your preferred Wifi network. Find your favorite song online and project the lyrics for all to see. Sing your heart out! Note: See the “Detailed Usage Guide”...
- Page 13 The Charging Indicator Light (4) will turn on to indicate charging. How to turn on the machine There are two steps to powering on the Illuminato Q4 Flip the Machine Power (26) switch towards the side labeled On to turn the machine on.
- Page 14 How to adjust the machine’s volume Spin the Machine Volume knob clockwise to increase the machine’s volume and counterclockwise to decrease it. If the projector light is on, a bar will also appear indicating volume level. How to access the machine’s settings Please note: The machine’s settings are distinct from the Smart OS settings.
- Page 15 Projector How to begin setting up the projector A. Carefully remove the machine’s lens cover B. Power on the machine as instructed in “How to turn on the machine” above. C. Connect to your preferred WiFi network (see the “How to connect to WiFi”...
- Page 16 How to adjust the keystone When the projector beam is at an angle to the screen, the result can be a distorted or trapezoidal image. The Lens Keystone (2) can adjust this shape to accommodate the angle. Spinning the Lens Keystone to the right (when one is behind the machine) will pitch the image up while...
- Page 17 How to adjust the angle of the projector machine itself The Illuminato Q4 comes with a large angle adjustment knob at the bottom front of the machine. Twist the knob to raise or lower the front angle of the machine.
- Page 18 Move the pill slider up to increase that mic’s volume and down to decrease it. How to add a third microphone You can add a third microphone to the Illuminato Q4 in the following ways A. For wired microphones or wireless microphones with plug-in adaptors, simply plug the microphone into the appropriate port, either the 6.5 mm Input (22) port for 6.5 mm mics or the...
