Summary of Contents for MASINGO Spirito H11
- Page 1 It’s time to like a pro Karaoke Machine Spirito H11 USER MANUAL...
- Page 3 User Manual Karaoke Machine Spirito H11...
- Page 5 This day and age, you always have your music handy. Why shouldn’t you have your karaoke handy too? Introducing the Spirito H11: a complete handheld karaoke system that’s always ready-to-sing. Bluetooth, AUX, USB, or MicroSD playback modes give you multiple options for maximum musical flexibility.
-
Page 6: Parts And Features
It’s the Whole Package! Parts & Features What’s included… 1 x Masingo karaoke microphone 1 x 3.5 mm AUX to 2*Micro USB adaptor 1 x DC 5V 1A charging cord 1 x Performer’s manual Microphone Diagram - Front Echo Control... - Page 7 Microphone Diagram - Bottom 3.5 mm headphone port DC 5V charging port/ 2*MicroUSB Port TF (MicroSD) port USB port...
- Page 8 Take Note Review Before Using 1) Keep this manual for future reference. 2) Adhere to all warnings. 3) Keep ventilation openings clear; do not block any of this micro- phone’s vents/openings. 4) Install and set up the microphone according to the manufacturer’s instructions provided in this manual.
- Page 9 Ready, set, sing! Quick Start Guide Charge your new H11 machine. Power it on, just like a dream. Pick your favorite playback setting. Download the app, free for the getting. Choose a LED design to display. #6 Select your music and sing away! Note: See the “Detailed Usage Guide”...
- Page 10 Never Miss a Note Detailed Usage Guide Microphone How to charge the microphone Plug in the microphone’s charging cable into the DC5V mi- crophone charging port (16) and into a wall outlet. Be sure to charge fully before each use. The indicator light (13) will turn on to indicate charging.
- Page 11 The microphone is ready to connect to Bluetooth as soon as it powers on. To use this feature, simply search for the microphone name (“Masingo”) under your smart device’s Bluetooth con- nection settings and connect like you would to any Bluetooth device.
- Page 12 How to use AUX mode (i.e. Playing music *from* an AUX-compatible device such as phone or MP3 player) When the microphone is on, plug the MicroUSB side of the AUX- to-MicroUSB adaptor into MicroUSB port (16) on the H11. Plug the AUX end into the device with which you wish to play music from.
- Page 13 How to connect via TWS (True Wireless Stereo) TWS (True Wireless Stereo) allows you to sync with other H11s. For this mode to work, you will need to have two Spirito H11 mi- crophones on hand. 1) Power on both microphones but DO NOT connect them *yet* via any of the above playback modes.
- Page 14 Light and Sound Effects How to adjust the microphone’s echo effects The Echo Control (3) adjusts the microphone’s reverberation effect. Press the + half of the button to increase how much your voice echoes. Press the - half of the button to decrease the effect. Note that the echo effect only works on sound from the micro- phone.
- Page 15 BAIAI LED What is the ‘ ’ app? BAIAI LED app is the Masingo-approved app for getting the most out of your microphone’s LED board. Through the BAIAI LED app, you can choose from an entire library of LED designs, create custom designs, write custom messages, and display sound equalizer bars.
- Page 16 How to find and display additional designs using the app 1) Open the app. 2) Select “Material” at the bottom of the app home screen. 3) “Material” contains two libraries:“Animation,” which shows moving designs, and “Pictures,” which shows stationary de- signs.
- Page 17 How to play music using the app BAIAI The H11 DOES NOT support the music player found in the app at this time. Please use one of the other playback options as detailed in the “Music” section above. How to activate equalizer bars on the microphone’s LED dis- play 1) Open the app.
- Page 18 How to display my custom design on my microphone’s LED board 1) Open the app. 2) Select “DIY” at the bottom of the home screen. 3) Click your preferred custom design to send it to your micro- phone's board. Note: *Hold* rather than click on your custom design to contin- ue to edit it, or to delete it.
-
Page 19: Troubleshooting Guide
When Things Go Flat Troubleshooting Guide Problem Solution The microphone The battery is depleted. Be sure to is not turning on. charge the microphone after each use. The USB or Mi- Ensure that the Power button on the croSD mode is microphone has been turned on and that the Music Volume (5) is turned up. - Page 20 Mode button (8) again to cycle through the correct mode). Ensure you have connected your device to “Masingo” NOT “Masingo LED.” “Mas- ingo LED” is only for the LED function board. If there is still no audio output, please charge the microphone.
- Page 21 The microphone Ensure that you are holding the mi- is making a feed- crophone by its handle, and that your back or hissing hand is not covering the speaker out- sound. put. Covering the speaker output (or holding the microphone by the speak- er) may cause feedback or hissing.
- Page 22 BAIAI LED then on again. app. The BAIAI LED app Bluetooth connec- After connecting “Masingo LED” to tion is separate from the Bluetooth Bluetooth in the playback mode. Please connect your BAIAI LED app, music according to the instructions in I cannot play the “How to connect via Bluetooth”...
- Page 23 The BAIAI LED app’s music player can- I cannot play music in the not be used to play music at this time. “Music” section Currently, only a single sample track will of the BAIAI LED play. app. The music function on the Bail AI LED app is ONLY for setting up the equal- izer bars (using the microphone icon in the top right corner).
- Page 24 If you encounter any issues with your microphone—or if Warranty you have any questions or comments—please feel free to contact us. Have your warranty information on hand for faster service. 844-262-7464 support@masingo.net www.masingo.net Love your new machine? We want to hear about it!
- Page 25 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
