MODULE-AIR AF-2423VT Series Operating Instructions & Parts Manual

WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
A) Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
B) Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent power
from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and
others by observing all safety information. Failure to comply could result in personal injury and/or property damage.
MODULE-AIR
(AF-2423VT VERTICAL AND AF-2423VT HORIZONTAL)

Description

This 8500 CFM Air Cleaner was designed for use as ambient air filtration where
airborne particles are prevalent. The air cleaner consists of 4 intakes and one
exhaust, one motor, one blower, electrical components and a riveted sheet metal
housing.
These units are about 410 pounds, and cannot be handled or transported without
the help of lifting tools.
It is recommended that you consult a professional electrician prior to installing this
product. If this Air Cleaner is to be used in an application that presents a potential fire
hazard, a fire protection expert should be consulted.

Unpacking

The machine should be unpacked carefully. Check if the machine and components
are consistent with those indicated in the Parts List. If any doubt arises or if parts
appear to be missing, contact your dealer.
MODEL
NUMBER
AF-24xx230 230V THREE PHASE
480V THREE PHASE
AF-24xx480
575V THREE PHASE
AF-24xx575
MODEL
TYPE:
NUMBER
(ALL) FORWARD INCLINE
SOUND LEVEL: 68 Db(A)
APPROXIMATE WIEGHT
AF-24xx
Operating Instructions & Parts Manual
READ AND SAVE THESE INSTRUCTIONS
Retain instructions for future reference.
AF-2423VT SERIES AIR CLEANER
MOTOR OPTIONS:
VOLTAGE HP
5 HP
5 HP
5 HP
BLOWER:
CFM:
8500
410 lbs
Hz AMP DRAW
60 12.6
60 6.3
60 5
