Thank you for purchasing this quality product. Be sure to check all packing materials
carefully for small parts, which may have come loose during shipment. Identify and count
all items and compare with the parts list shown below. It is recommended to have two
people during assembling and to remove the back and base of the furniture out from the box.
Please follow the drawings below to assemble the item
NO.
A
Seat
B
Left Backrest
C
Middle Backrest
D
Right Backrest
E
Left Wing
F
Right Wing
G
Plug
ASSEMBLY INSTRUCTIONS
VEGA COLLECTION
ITEM# : U3822-30-PBK
DESCRIPTION :
Parts List
DESCRIPTION
All images shown are for illustration purpose only.
Actual product may vary due to product enhancement.
Page 1 of 2
VEGA SOFA PREMIER BLACK
SKETCH
Q'TY
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
Advertisement
Table of Contents
Related Manuals for New Classic Furniture VEGA U3822-30-PBK
Summary of Contents for New Classic Furniture VEGA U3822-30-PBK
- Page 1 ASSEMBLY INSTRUCTIONS VEGA COLLECTION ITEM# : U3822-30-PBK DESCRIPTION : VEGA SOFA PREMIER BLACK Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
- Page 2 ASSEMBLY INSTRUCTIONS VEGA COLLECTION ITEM# : U3822-30-PBK DESCRIPTION : VEGA SOFA PREMIER BLACK Step 2: Step 1: Attach the Left Wing (E) and Right Wing Attach Backrest (B/C/D) to the Seat (A). (F) to the Backrest (B/D). Step 3: Connect power and turn on and off the light by pressing the button. Open the footrest by pulling the handle.
