New Classic Furniture U3969-30p1-eby Assembly Instruction

Thank you for purchasing this quality product. Be sure to check all

packing materials carefully for small parts, which may have come loose

list and/or hardware list shown below. It is recommended to have two

people during assembling and to remove the backs and base of the furniture

out from the box.

Please follow the drawings below to assemble the item

Step 1:Please align and insert the metal

bracket (F) on the back rest onto the metal

bracket (M) of the seat

metal brackets (F) and (M) are inserted all

the way and secured into position.

Assembly Instruction

.Please

make sure the

Step 2: Please align and insert the LSF wing

and RSF wing onto the back rest.Please make

sure the wings are inserted all the way and

secured into position.

LSF

All images shown are for illustration purpose only.

Actual product may vary due to product enhancement.

RSF
