Thank you for purchasing this quality product. Be sure to check all packing materials
carefully for small parts, which may have come loose during shipment. Identify and count
all items and compare with the parts list shown below. It is recommended to have two
people during assembling and to remove the back and base of the furniture out from the box.
Please follow the drawings below to assemble the item
NO.
A
Seat
B
Left Side Facing (LSF) Backrest
Console backrest
C
Right Side Facing (RSF) Backrest
D
Left Side Facing (LSF) Wing
E
F
Right Side Facing (RSF) Wing
G
Power Cable 29V
Transformer Plug
H
ASSEMBLY INSTRUCTIONS
TANGO COLLECTION
ITEM# : U396-25P1
DESCRIPTION : TANGO CONSOLE LOVESEAT
W/SPEAKER & PWR FR
PARTS LIST
DESCRIPTION
All images shown are for illustration purpose only.
Actual product may vary due to product enhancement.
Page 1 of 5
SKETCH
QTY
1PC
1PC
1PC
1PC
1PC
1PC
1PC
1PC
49901886
Advertisement
Related Manuals for New Classic Furniture TANGO Series
Summary of Contents for New Classic Furniture TANGO Series
- Page 1 ASSEMBLY INSTRUCTIONS TANGO COLLECTION ITEM# : U396-25P1 DESCRIPTION : TANGO CONSOLE LOVESEAT W/SPEAKER & PWR FR Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
- Page 2 ASSEMBLY INSTRUCTIONS TANGO COLLECTION ITEM# : U396-25P1 DESCRIPTION : TANGO CONSOLE LOVESEAT W/SPEAKER & PWR FR Step 1: Locate the console backrest (C) at the bottom of seat (A). Step 2： Unscrew the knob screws from the console backrest (C). All images shown are for illustration purpose only.
- Page 3 ASSEMBLY INSTRUCTIONS TANGO COLLECTION ITEM# : U396-25P1 DESCRIPTION : TANGO CONSOLE LOVESEAT W/SPEAKER & PWR FR Step 3: Open the zipper at the back of the console of seat (A) and attach the console backrest (C) to the correct position by turning the knob screws from inside the zipper counterclockwise until the console backrest (C) is secured in place.
- Page 4 ASSEMBLY INSTRUCTIONS TANGO COLLECTION ITEM# : U396-25P1 DESCRIPTION : TANGO CONSOLE LOVESEAT W/SPEAKER & PWR FR Step 5： Insert the LSF wing (E) to the LSF backrest (B) and insert the RSF wing (F) to the RSF backrest (D). Make sure the wings are secured in position. Step 6: At the back of chair (A), locate the power cable secured at the middle of the metal frame.
- Page 5 ASSEMBLY INSTRUCTIONS TANGO COLLECTION ITEM# : U396-25P1 DESCRIPTION : TANGO CONSOLE LOVESEAT W/SPEAKER & PWR FR Step 7: Connect the Power Cable 29V (G) to the power socket on the back of seat (A). Step 8 Connect the power and open/close the footrest by pressing the power buttons. All images shown are for illustration purpose only.
