Summary of Contents for ADIR 615
- Page 2 PARTS LIST Part Description QTY. Part Description QTY. Medium Screw Side Bar Long Screw sliding bars Acorn Nut L Bars Knob Bolt Locking Caster Wing Nut Caster...
- Page 3 Insert Casters (Part D&E) into bottom of Side Bars (Part A - bigger thread openings facing down for casters). Attach both locking casters to same side bar. Attach L frames (Part C) together. Adjust to file size, inserting knob bolts (Part I) into appropriate holes.
- Page 4 Attach Side Bars (Part A) to L Bars (Part C) according to picture. Insert Long screw (Part G) into upper two holes through L Bars tightening with Acorn Nuts (Part H), third screw into bottom hole tightening into L Bar frame Upper holes of side bars...
