- Page 1 Mobile Plan Center Assembly Instructions for MODEL Page 1 of 4 www.adircorp.com...
- Page 2 Mobile Plan Center Assembly Instructions for MODEL PARTS LIST Item Description QTY. Item Description QTY. Black Plastic Cap Plastic Spacer L-frame Locking Caster Upper Crossbar Lower Caster Crossbar (with bigger holes for casters) Upper Wing Nut Panel all extensions facing same way Knob Bolt Washer Lower...
- Page 3 Mobile Plan Center Assembly Instructions for MODEL Insert casters (Part L&M) into Lower Crossbars Attach lower crossbars (part C) to L Frames (Part A) (part C – the ones with bigger holes for casters). using Long Screw (Part G) and Acorn Nut (part F), Attach both locking casters to same crossbar.
- Page 4 Mobile Plan Center Assembly Instructions for MODEL Attach upper crossbar (Part B) to the inside top of Place plastic spacers (part K) onto holes of top L-Frames using long screws (Part G) and Acorn Nut crossbars. Insert medium screw (part H) into plastic (Part F).
