Summary of Contents for NeurOptics VIP-400
- Page 1 - 400 Pupillometer ® Instructions For Use...
-
Page 2: Table Of Contents
The VIP-400 Pupillometer is a handheld optical scanner which measures pupil size at different background illuminations. The results obtained from the VIP-400 scans are used for information only and are not to be used for clinical diagnostic purposes. The VIP-400 should only be operated by properly trained clinical personnel, under the direction of a qualified physician. -
Page 3: Warnings And Cautions
MRI environment or in the vicinity of high- frequency surgical diathermy equipment, defibrillators, • The VIP-400 is intended for use by trained clinical or short-wave therapy equipment. Electromagnetic personnel, under the direction of a qualified physician. -
Page 4: Getting Started
Plug (C) Start Guide Initial Set-Up Ex. 1 To set up the VIP-400 for first-time use, please refer to the Power Up section below, ensuring the • VIP-400 is fully charged and Date/Time are set accurately prior to use. Power Up Charging the VIP-400 Pupillometer •... -
Page 5: Measuring Pupils
If the VIP-400 Pupillometer is not in the Charging Station, to conserve battery life it will: • Go into sleep mode after 4 minutes. To turn ON, touch the screen or push any button. • Power down after an additional 6 minutes. - Page 6 Patient ID and select (Ex. 18). Confirm the patient information on the screen is correct and select Accept (Ex. 16). The VIP-400 will display the Patient ID and read Ready to Scan (Ex. 17). Ex. 18 Set Measurement Protocol From the Main Menu screen (Ex.
- Page 7 (Ex. 22), while a red frame indicates the pupil needs to be re-centered on the screen before the measurement is initiated (Ex. 23). Once the green frame appears, release the OD or OS button, holding the VIP-400 in place for approximately two seconds until the results screen is displayed. When the pupil measurement is complete, pupil data are analyzed and then results are displayed.
-
Page 8: Download Data
Only the last measurement’s video can be played back. Once the VIP-400 has powered off, or if the OD or OS button is pressed during the scan, the last video is not accessible (Ex. 27). -
Page 9: Print Data
Delete Records Ex. 36 Ex. 37 To delete records off of the device memory of the VIP-400, navigate to the Settings Menu and press Delete then select Yes to proceed to delete record (Ex. 38). Records on the device can be deleted for a specific Patient ID or All Records. -
Page 10: Troubleshooting
(truncation or expansion) to be used for all future scans. Contact NeurOptics Ex. 39 for additional information. System Information Select System (Ex. 37) to view the VIP-400 ’s system information, displaying the Serial Number, Software Application, and Firmware versions of the device. Troubleshooting Issue Possible Reason Solution 1. -
Page 11: Power Off
Isopropyl alcohol (IPA)-based cleaning solutions, in formula concentrations up to 70% IPA, are recommended for use in cleaning the VIP-400, Charging Station, and eye cup. Do not use chemicals that can damage the VIP-400 and Charging Station surface. Some chemicals can weaken or damage plastic parts and may cause instruments to not operate as intended. -
Page 12: Customer Service
(bleach) when cleaning equipment. If products containing sodium hypochlorite (bleach) are used to clean the LCD of the VIP-400, the cleaning process should be followed by a second cleaning using a clean, soft, lint-free cloth and up to 70% IPA to ensure that all bleach residue is completely removed from the LCD. -
Page 13: International Symbol Definition
Article 11(2) of the European Electrical and Electronic Equipment (WEEE) Electronic Community Directive 2002/96/ 2012/19/EU Directive for recycling of Equipment EC (WEEE) electronic equipment. Do not dispose of this product in unsorted municipal waste stream NeurOptics® VIP®-400 Pupillometer System—Instructions for Use ©2023 NeurOptics, Inc. - Page 14 Symbol Reference No: 5140 electromagnetic e.g. in the medical electrical area that radiation include RF transmitters or that intentionally apply RF electromagnetic energy for diagnosis or treatment NeurOptics® VIP®-400 Pupillometer System—Instructions for Use ©2023 NeurOptics, Inc.
-
Page 15: Wireless Printing Range And Frequency
Up to 100 cm Wireless Printing low energy operation frequency 2.4 GHz 9223 Research Drive Irvine, CA 92618 | USA p: 949.250.9792 Toll Free North America: 866.99.PUPIL info@NeurOptics.com NeurOptics.com NeurOptics® VIP®-400 Pupillometer System—Instructions for Use ©2023 NeurOptics, Inc. VIP-400 IFU Rev A (HOMA-BZEREC)
