Altelix NF141206-T01 Installation Manual

Page-4 NF141206-T01 Phone Box Installation Guide
WARNING: INSTALLATION OF THIS PRODUCT NEAR POWERLINES IS
DANGEROUS. FOR YOUR SAFETY, FOLLOW THE INSTALLATION DIRECTIONS
Under some conditions, this enclosure may not prevent electrocution. Users should keep
enclosure away from any overhead wires. If enclosure contacts a power line, any initial
protection could fail at any time. IF ENCLOSURE NEARS ANY OVERHEAD WIRES,
IMMEDIATELY LET GO, STAY AWAY, AND CALL UTILITY COMPANY
THIS ENCLOSURE IS DESIGNED TO BE INSTALLED BY A LICENSED
ELECTRICIAN OR QUALIFIED INSTALLER
Warning: To avoid electric shock, grounding must be installed by the installer as part of the
installation. The unit must be grounded and installed in accordance with National Electrical
Codes (NEC) and any local codes. Note that non-metallic enclosures do not provide
grounding between conduit connections.
Warning: Enclosure must be locked when energized to prevent unauthorized access and
shock hazard.
Important: Look over the site before beginning installation, and anticipate possible
hazards. Select a safe site to install the enclosure.
If you have power lines in the area, call your local electric utility for assistance.
NEVER work alone; always have someone near who can summon help.
Check weather conditions. Be sure that the area is not slippery and make sure that rain or
thunderstorms are not predicted for the day you install the enclosure.
If you need to use a ladder, make sure it is made of non-conductive (non-metallic)
material.
Enclosures improperly installed or installed to an inadequate structure are susceptible to
wind damage that can be very serious or even life threatening. Ensure that the installation
is properly grounded. Ensure that the enclosure is properly secured and structurally sound
to support all loads (weight, wind & ice).

Rooftop Installation Warning

DO NOT assume that just because you're on a roof, you're isolated from ground. You may
still be electrocuted or fall off the roof.
Altelix LLC USA: 866-660-WIFI (9434) International: +1 561-660-9434 sales@altelix.com www.altelix.com
Copyright (C) 2023 Altelix LLC. All rights reserved. Altelix and the Altelix logo are Trademarks and/or Registered Trademarks of Altelix LLC.
Specifications are subject to change without notice. See www.altelix.com for most current information
IS0192 Rev A 02/09/23
Page-1 NF141206-T01 Phone Box Installation Guide

Wiring the NF141206-T01 Phone Box

Aluminum Plate
2. Once the aluminum
plate is removed, run
your phone cable into
the box through the
cable gland.
Phone Cable Gland
Phone Cable
(not included)
Altelix LLC USA: 866-660-WIFI (9434) International: +1 561-660-9434 sales@altelix.com www.altelix.com
Copyright (C) 2023 Altelix LLC. All rights reserved. Altelix and the Altelix logo are Trademarks and/or Registered Trademarks of Altelix LLC.
Specifications are subject to change without notice. See www.altelix.com for most current information
IS0192 Rev A 02/09/23
1. Remove the (4) screws
securing the aluminum
plate.
Note the NF141206-T01 is
shipped with the phone
jack plate removed to
facilitate wiring.
Mounting Plate Screws (4)
