StarTech.com DKT31CDHPD3 Quick Start Manual

USB-C Multiport Adapter - 4K 60Hz HDR10 HDMI or DisplayPort - 3 x USB (10Gbps) - 100W PD - Extended Cable
Product ID
DKT31CDHPD3
Product Diagram(Side A)
1
(Side B)
(Side C)
(Side D)
Requirements
Computer
•
DP Alt Mode enabled USB-C Port
•
For the latest drivers, manuals, product information, technical specifications, and
declarations of conformance, please visit:
Package Contents
USB-C Multiport Adapter x 1
•
Quick-Start Guide x 1
•
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
2 3
4 5 3
6
7
www.StarTech.com/DKT31CDHPD3
Component
•
1
Built-in USB-C Host Cable
•
•
•
2 USB-C Data/Charge Port
•
•
•
2x USB-A Data/Charge
3
•
Port
•
•
•
•
4 HDMI Output Port
•
•
•
•
5
DisplayPort Output Port
•
•
•
USB-C 100 W Power
6
•
Delivery Port
•
7 Gigabit Ethernet Port
•
Quick-Start Guide
Function
Connect to a USB-C Port on a Host Computer
USB 3.2 Gen 2 (10 Gbps)
Power Delivery 3.0 Specification
Connect and/or charge a USB-C Peripheral
USB-C Power Adapter required for charging
•
USB 3.2 Gen 2 (10 Gbps)
Supports 5 V/3 A (15 W) charging
Connect and/or charge USB-A Peripherals
USB-C Power Adapter required for charging
•
USB 3.2 Gen 2 (10 Gbps)
Supports BC 1.2 5 V/1.5 A (7.5 W) charging
Via DisplayPort 1.4 DP Alt Mode
Connect an HDMI Display Device
HDMI 2.0b HDR10
Up to 4K (4096x2160) 60 Hz
Via DisplayPort 1.4 DP Alt Mode
Connect a DisplayPort Display Device
DisplayPort 1.4
Up to 4K (4096x2160) 60 Hz
Via DisplayPort 1.4 DP Alt Mode
Connect a USB-C Power Adapter
USB Power Delivery 3.0 (up to 100 W, with up
to 85 W available for charging)
Connect a CAT 5e/CAT 6 cable to establish a
network connection
10/100/1000 Mbps
Manual Revision: December 2, 2022 1:28 PM
