StarTech.com DKT31CVHPD3 Quick Start Manual

USB-C Multiport Adapter - HDMI 4K 60Hz HDR10 or VGA - 3 x USB (10Gbps) - 100W PD - Extended Cable
Product ID
DKT31CVHPD3
Product Diagram (Side A)
1
(Side B)
(Side C)
Component
Connect to a USB-C Port on a Host Computer
•
Built-in USB-C Host
1
USB 3.2 Gen 2 (10 Gbps)
•
Cable
Power Delivery 3.0
•
Connect and/or charge a USB-C Peripheral
•
USB-C Power Adapter required for charging
USB-C Data/Charge
•
2
Port
USB 3.2 Gen 2 (10 Gbps)
•
Supports 5V/3A (15 W) charging
•
Connect and/or charge USB-A Peripherals
•
USB-C Power Adapter required for charging
2x USB-A Data/
•
3
Charge Ports
USB 3.2 Gen 2 (10 Gbps)
•
Supports BC 1.2 5 V/1.5 A (7.5 W) charging
•
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
2 3
3 4 5
6
Function
Specification
Connect a VGA Display Device
•
4
VGA Output Port Up to 1080p (1920x1200/1920x1080) 60 Hz
•
Via DisplayPort 1.4 DP Alt Mode
•
Connect an HDMI Display Device
•
HDMI 2.0b HDR10
•
5
HDMI Output Port
Up to 4K (4096x2160) 60 Hz
•
Via DisplayPort 1.4 DP Alt Mode
•
Connect a USB-C Power Adapter
•
USB-C 100 W Power
6
USB Power Delivery 3.0 (up to 100 W, with up to
•
Delivery Port
84 W available for charging)
Requirements
Computer
•
DP Alt Mode enabled USB-C Port
•
For the latest drivers, manuals, product information, technical specifications, and
declarations of conformance, please visit:
Package Contents
USB-C Multiport Adapter x 1
•
Quick-Start Guide x 1
•
Quick-Start Guide
www.StarTech.com/DKT31CVHPD3
Manual Revision: February 11, 2022 4:06 PM
