ETS AP-120EDM Operating Instructions Manual

Hide thumbs Also See for AP-120EDM:
Table of Contents

Advertisement

Quick Links

Download this manual
AP-
120EDM/
AP-120
Operating Instructions
Thank you for buying our air cleaner. Each system
is carefully manufactured and subjected to a test
run to ensure safety and reliability. Please read the
instructions carefully before initial use and save
them for future reference.
www.ets-products.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-120EDM and is the answer not in the manual?

Questions and answers

Related Manuals for ETS AP-120EDM

Summary of Contents for ETS AP-120EDM

  • Page 1 Operating Instructions Thank you for buying our air cleaner. Each system is carefully manufactured and subjected to a test run to ensure safety and reliability. Please read the instructions carefully before initial use and save them for future reference. www.ets-products.com...

  • Page 2: Table Of Contents

    Specifications Areas of application Test reports System overview Installation instructions Commissioning Control and display field Remote control AP-120EDM tuya app control AP-120EDM Maintenance and cleaning Safety instructions Contact TuyaSmart App Control; available in Apple App Store & Google Play Store.

  • Page 3: Scope Of Delivery

    AP- 120 EDM / AP- 120 Scope of delivery Air cleaner: Power cable: Operating instructions: Remote control (for AP-120 EDM): 1 Specifications Recommended area: 140 m² Air volume (CADR): 1200 m³/h Mains voltage*: 110 V / 230 V Frequency*: 50 Hz / 60 Hz Power: 120 W Dimensions (mm):...

  • Page 4: Areas Of Application

    (2) titanium dioxide photo-catalyst in conjunction with two (2) UV-C sterilization lamps with a wavelength of 254nm and a plasma generator (bi-polar). ETS air cleaning systems are used to effectively remove toxins, viruses, bacteria, pathogens, dust, allergens, and odors from the ambient air.

  • Page 5: Test Reports

    AP- 120 EDM / AP- 120 Test reports The system has been tested and certified for its efficacy. The test reports can be looked up on the Institute website (http://english.gdim.cn) using the test certificate numbers below. Upon request we can also send you a soft copy of any required test report.

  • Page 6: System Overview

    AP- 120 EDM / AP- 120 System overview 1A top cover (AP-120) 5 Control circuit (AP-120 EDM) 6 UV-C lamp 1B top cover 7 Prefilter (Touch Screen AP-120 EDM) 8 Protective covering 2 Air outlet 9 Housing 3 Activated carbon filter 10 Plate with wheels 4 HEPA filter...

  • Page 7: Installation Instructions

    AP- 120 EDM / AP- 120 Installation instructions The device must be freestanding during operation with space of at least 30 cm to the rear and to both sides. The rear air inlet, the lateral sensors, and the air outlets must remain free and may not be covered. Commissioning The systems are tested and delivered ready to operate.

  • Page 8: Control And Display Field

    AP- 120 EDM / AP- 120 Control and display fields Modell AP-120 Switch actuation UV-C lamp switch Model AP-120 EDM Display Numerical display: PM2.5, HCHO, TVOC, CO2, Temperature, Humidity, Filter Status, Timer, Date. Status display: Cleaning level, night mode, automatic/manual mode, WiFi Status. Function button: On/Off Automatic/Manual...

  • Page 9: Remote Control Ap-120Edm

    AP- 120 EDM / AP- 120 Reset after replacement: After replacing the HEPA filter, press the On/Off button and the Night Mode button simultaneously for at least five seconds. The machine emits a signal tone and the Filter Status is reset to 100%. The lifetime of the HEPA Filter will now be calculated anew.
  • Page 10 AP- 120 EDM / AP- 120 On/off: Press the On/Off button to switch on the device.By default, the device runs at Fan Level 1 in manual mode. Auto mode: In automatic mode, the fan level is controlled automatically according to air quality.
  • Page 11 AP- 120 EDM / AP- 120 Tuya Smart App Control (AP-120 EDM) 1. Scan the QR code in order to download and install the Tuya Smart App. Start the Tuya Smart App by clicking on „log in“ (or sign up for the first time) or „try now“...
  • Page 12 AP- 120 EDM / AP- 120 4. Within the Tuya App click „ADD DEVICE“ then select „AUTO SCAN“ and enable „access location, Wifi and Bluetooth“. Please ensure that the device and your smartphone/tablet is using the same network. Click on „AUTO SCAN“...
  • Page 13 AP- 120 EDM / AP- 120 Now you can give your AP a name and can control it via internet using your smart phone or tablet.

  • Page 14: Maintenance And Cleaning

    AP- 120 EDM / AP- 120 Maintenance and cleaning To clean the air, the system uses several filters and air cleaning systems simultaneously: Prefilter The prefilter filters out large particles such as human hair, animal hair, lint, etc. HEPA H14 filter The HEPA H14 filter removes smoke, dust, pollen, allergens, toxins, and fine particles larger than 0.3 μm.
  • Page 15 After the cover is removed, the filter packages can be removed from the front. Note for model AP-120EDM: The control panel is in the cover. The cover must not be left hanging down onto the supply line. Two people are needed to remove the cover.

  • Page 16: Safety Instructions

    AP- 120 EDM / AP- 120 Safety instructions • Before use, the rear housing cover must be completely closed. • Do not open the rear cover or the maintenance panel while the device is in use. • Before connecting the machine to the power source, ensure that the voltage indicated on the type plate is the same as the mains voltage in your region.

  • Page 17: Contact

    AP- 120 EDM / AP- 120 Manufacturer ETS Products Philippines Inc. Berthaphil 4 Warehouse 2C Civil Aviation Complex Clark Clark Freeport, Pampanga 2023, Philippines Contact +63 (0)45 499 56 07 Phone E-Mail inquiry@ets-products.ph Internet www.ets-products.ph You can find more information and technical data about air cleaning systems on...
