AP-40
User Manual
Thank you for buying our air purifier. Each unit has been carefully manufactured to
ensure safety and reliability. Please read the instructions carefully before first use and
keep the manual for future reference.
www.ets-products.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-40 and is the answer not in the manual?

Questions and answers

Related Manuals for ETS AP-40

Summary of Contents for ETS AP-40

  • Page 1 AP-40 User Manual Thank you for buying our air purifier. Each unit has been carefully manufactured to ensure safety and reliability. Please read the instructions carefully before first use and keep the manual for future reference. www.ets-products.com...
  • Page 2 AP-40 User Manual Technical Data AP-40 Aerea 40 m² Clean Air Delivery Rate 320 m³/h Voltage 110 V / 230 V Frequency 50 Hz or 60Hz Rated Power 60 W Dimensions (mm) 620 x 391 x 227 Net Weight (kg)

  • Page 3: Packing List

    AP-40 User Manual The voltage and frequency depend on the standard of the country or region in which the devices are intended of being used. The device data can be found on the product label. Use only devices that are suitable for your region.
  • Page 4 AP-40 User Manual Features: The device is equipped with a highly efficient filtration and cleaning system, including HEPA H13 filter, activated carbon filter with high iodine content, TIO2 photocatalyst filter, plasma and UV sterilization lamp with a wave length of 254 nm. It can remove PM 2.5, formaldehyde, benzene, ammonia, TVOC, dioxide, sulfur, odors, smoke, dust, etc.
  • Page 5 AP-40 User Manual Pre-use Preparation 1. Place the device horizontally upright 2. Please make sure that the rear case cover is tightly closed. 3. Insert the power plug into the back of the device as shown. 4. After connecting to the power grid, you will hear a beep indicating that the device is in Standby Mode.

  • Page 6: Air Quality Sensor

    AP-40 User Manual Intelligent Automatic Mode (recommended use mode) Press the power button , the main air duct is opened and the symbol will be displayed. By default, the purifier is in the Intelligent Automatic Mode, thus the purifier will automatically adjust its purification performance based on the current air quality.
  • Page 7 AP-40 User Manual Manual Adjustment of Purification Level The air purification level can be set manually in 4 levels as required: quiet, low, middle, high. The air quality sensor continues to work and is not affected by the respective setting.

  • Page 8: Sleep Mode

    AP-40 User Manual Timer By pressing the timer button you can pre-set the operating time to 1h, 4h, 8h, 12h and 24h or activate the stand-by mode. Press repeatedly to choose the desired setting. Sleep Mode By activating the sleep mode, all indicator lights are switched off, the cover of the main air duct is closed and the cleaning cycle is now diverted to the front air duct, thus creating a comfortable and quiet environment for your sleep.

  • Page 9: Child Safety Lock

    AP-40 User Manual Child Safety Lock By pressing the button, the control panel will be locked. The device, in this mode, can no longer be set by using the control panel. Press again to unlock the control panel. Multi-Layer Air Filter...

  • Page 10: Remote Control

    AP-40 User Manual Remote Control Automatic Mode On/Off (intelligent Air Purification) Manual Mode UV Sterilisation Sleep/Night Mode (quiet operation) Confirm HEPA Filter Replacement (press 5 seconds) Confirm UV-Lamp Replacement (press 5 seconds) (Note: Our products are updated irregularly, the layout of the remote control may...
  • Page 11 AP-40 User Manual 4. HEPA filter: The air purifier saves the usage time and reminds you to replace the filter. flashes with multiple beeps, the HEPA filter must be replaced. Please replace immediately. Reset timer: Press the "HEPA Reset" button and hold it down for 5 seconds after changing the filter.

  • Page 12: Important Safety Instructions

    AP-40 User Manual Important Safety Instructions  Before use, the rear cover of the housing must be completely closed.  Do not open the rear cover of the unit during use.  Before connecting the device to the power grid, check that the voltage and frequency indicated on the product label matches the voltage and frequency used in your region.
  • Page 13 AP-40 User Manual ETS Products Philippines Inc. Berthaphil IV Warehouse 2C, Civil Aviation Complex, Clark Freeport Zone, Pampanga 2023, Philippines Contact (Europe) Contact (Asia) Phone: +63 (0)45 499 5607 Phone: +49 2204 9673 650 Email: inquiry@ets-products.ph Email: europe@ets-products.com www.ets-products.ph...
