ETS AP-120EDM Operating Instructions Manual

Hide thumbs Also See for AP-120EDM:
Table of Contents

Advertisement

Quick Links

Download this manual
AP-120EDM /
AP-120
Operating instructions
Thank you for buying our air cleaner. Each system
is carefully manufactured and subjected to a test
run to ensure safety and reliability. Please read the
instructions carefully before initial use and save
them for future reference.
www.ets-products.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-120EDM and is the answer not in the manual?

Questions and answers

Related Manuals for ETS AP-120EDM

Summary of Contents for ETS AP-120EDM

  • Page 1 AP-120EDM / AP-120 Operating instructions Thank you for buying our air cleaner. Each system is carefully manufactured and subjected to a test run to ensure safety and reliability. Please read the instructions carefully before initial use and save them for future reference.

  • Page 2: Table Of Contents

    Areas of application Test reports System overview Installation instructions Commissioning Control and display field Remote control AP-120EDM tuya app control AP-120EDM Maintenance and cleaning Safety instructions Contact TuyaSmart App Steuerung; available from theApple App Store & the Google Play Store.

  • Page 3: Scope Of Delivery

    AP-120E D M / A P-120 Scope of delivery Air cleaner: Power cable: Operating instructions: Remote control (for AP-120 EDM): 1 Specifications Recommended area: 140 m² Air volume (CADR): 1200 m³/h Mains voltage*: 110 V / 230 V Frequency*: 50 Hz / 60 Hz Power: 120 W Dimensions (mm):...

  • Page 4: Areas Of Application

    HEPA H13 filter, an activated carbon filter, a titanium dioxide photo-catalyst filter, a UV sterilization lamp with a 254-nm wavelength, and a plasma generator. ETS air cleaning systems are used to effectively remove toxins, viruses, bacteria, pathogens, dust, allergens, and odors from the ambient air. Test reports The system has been microbiologically tested.

  • Page 5: System Overview

    AP-120E D M / A P-120 System overview 1A top cover (AP-120) 5 Control circuit (AP-120 EDM) 6 UV-C lamp 1B top cover 7 Prefilter (Touch Screen AP-120 EDM) 8 Protective covering 2 Air outlet 9 Housing 3 Activated carbon filter 10 Plate with wheels 4 HEPA filter...

  • Page 6: Installation Instructions

    AP-120E D M / A P-120 Installation instructions The device must be freestanding during operation with space of at least 30 cm to the rear and to both sides. The rear air inlet, the lateral sensors, and the air outlets must remain free and may not be covered. Commissioning The systems are tested and delivered ready to operate.

  • Page 7: Control And Display Field

    AP-120E D M / A P-120 Control and display fields Modell AP-120 Switch actuation UV-C lamp switch Model AP-120 EDM Display Numerical display: PM2.5, time preset Status display: Speed status display, air filter replacement display, sleep mode, automatic mode. Function button: As on a remote control.

  • Page 8: Remote Control Ap-120Edm

    AP-120E D M / A P-120 Reset after replacement: After replacing the HEPA filter, press the On/off button and the speed button simultaneously for five seconds. The machine emits a signal tone. The icon no longer flashes. This means that the filter has been replaced and the duration of filter use re-calculated.
  • Page 9 AP-120E D M / A P-120 On/off: Press the On/off button to switch on the device. By default, the device runs at Fan Level 1 in manual mode. Auto mode: In automatic mode, the fan level is controlled automatically according to air quality Timer: Shut-off time can be planned.
  • Page 10 AP-120E D M / A P-120 Tuya Smart App Control (AP-120 EDM) 1. Scan the QR code in order to download and install the Tuya Smart App. 2. Get the Tuya Smart App started by clicking on „log in“ (or sign up for the first time) or „try now“...
  • Page 11 AP-120E D M / A P-120 4. Click „ADD DEVICE“ then select „AUTO SCAN“ amd enable „access location, Wifi and Bluetooth“. Please ensure that the device and your smartphone is using the same network. Click on „AUTO SCAN“ to find available devices.
  • Page 12 AP-120E D M / A P-120 5. Select the new device on your screen and connect it with the system. 6. Now you have full control of the device via your smartphone...

  • Page 13: Maintenance And Cleaning

    AP-120E D M / A P-120 Maintenance and cleaning To clean the air, the system uses several filters and air cleaning systems simultaneously: Prefilter The prefilter filters out large particles such as human hair, animal hair, lint, etc. HEPA H13 filter The HEPA H13 filter removes smoke, dust, pollen, allergens, toxins, and fine particles larger than 0.3 μm.
  • Page 14 After the cover is removed, the filter packages can be removed from the front. Note for model AP-120EDM: The control panel is in the cover. The cover must not be left hanging down onto the supply line. Two people are needed to remove the cover. Place it on the housing after the filters have been removed.

  • Page 15: Safety Instructions

    AP-120E D M / A P-120 Safety instructions • Before use, the rear housing cover must be completely closed. • Do not open the rear cover or the maintenance panel while the device is in use. • Before connecting the machine to the power source, ensure that the voltage indicated on the type plate is the same as the mains voltage in your region.

  • Page 16: Contact

    Manufacturer ETS Products Philippines Inc. Berthaphil 4 Warehouse 2C Civil Aviation Complex Clark Clark Freeport, Pampanga 2023 Philippines An ETS Products Group company Contact Phone +49 2204 / 967360 E-Mail europe@ets-products.com Internet www.ets-products.com You can find more information and technical data about air cleaning systems on...

This manual is also suitable for:

Ap-120
