- Page 1 ISO Analyze 6DOF ISO Base ™ Image Analysis Software Model 023-08 USER GUIDE 900 Asbury Ave • Norfolk, Virginia 23513 • USA • Tel: 757-855-2765 • WWW.CIRSINC.COM...
- Page 2 OVERVIEW The CIRS 6DOF ISO Base, Model 023-08 is an optional accessory of ISO Cube. It is designed for positioning and leveling of ISO Cube and quick calculation of complex 3D shifts of RT treatment systems with an integrated robotic couch.
- Page 3 USE OF THE 6DOF ISO BASE ™ To check the 6DOF shifts the following procedure is recommended: 1. Acquire Image Reference Set Align the ISO Cube to the imaging system that is to be used to acquire the image refer- ence set.
- Page 4 3. Daily QA Shifts Setup For daily QA checks of the DOF shifts the 6DOF ISO base is registered to an index- ing bar of the Linac couch and leveled. The ISO Cube is then placed in the ISO alignment pocket and the whole assembly is aligned to the Linac’s light field and la- sers by translating only the couch about the orthogonal axes.
- Page 5 CIRS not to comply with documented order specifications. You must return the product to CIRS within 30 calendar days of the issuance of the RMA. All returns should be packed in the original cases and or packaging and must include any accessories, manuals and documentation that shipped with the product.
- Page 7 COMPUTERIZED IMAGING REFERENCE SYSTEMS, INC. 900 Asbury Ave Norfolk, Virginia 23513 USA Toll Free: 800.617.1177 Tel: 757.855.2765 Fax: 757.857.0523 Email admin@cirsinc.com www.cirsinc.com Technical Assistance 1.800.617.1177 2016 Computerized Imaging Reference Systems, Inc. All rights reserved. © Computerized Imaging Reference Systems, Inc. has Specifications subject to change without notice.
