- Page 1 USER MANUAL M-OF7030 M-OF7040 M-OF7050 DOP User manual_ENG.indd 1 14/11/2013 12:05:00...
-
Page 2: Safety Precautions
Safety Precautions Thank you for purchasing this product. Please Please don't change the fuse on the power read through these operating instructions cord without professional guidance, using so you will know how to operate your model improper fuse may cause damage to this unit properly. -
Page 3: Expanding System
Safety Precautions 1. Never disassemble or adjust the unit without any professional guidance. For details, please consult any professional car shop / dealer for inquiry. 2. If the front panel or TFT monitor is dirty, please use a clean silicone cloth and neutral detergent to wipe off the spot. -
Page 4: Table Of Contents
Search for a folder ......... 16 Contents ............3 Repeat ............. 16 Produc overview ........... 4 Repeat A-B ..........17 M-OF7030 Front Panel ......4 Shuffle (Random) oplay ......17 M-OF7040 Front panel ......5 Select audio mode ........17 M-OF7050 Front view ....... 6 Select subtitle language ...... -
Page 5: Produc Overview
M-OF7030 Product overview Front panel 11 10 Notice: The graphic in this manual is for reference only, and may be different from the actual unit. 1. [MENU] Button Press to switch between the available audio/video sources applied to the unit. -
Page 6: M-Of7040 Front Panel
M-OF7040 Product overview Front panel Notice: The graphic in this manual is for reference only, and may be different from the actual unit. 1. [VOL/ ] Knob Press to turn the unit ON. Press and hold to turn the unit OFF. Rotate to adjust the volume. -
Page 7: M-Of7050 Front View
M-OF7050 Product overview Front Panel Notice: The graphic in this manual is for reference only, and may be different from the actual unit. 1. [VOL/ ] Knob Press to turn the unit ON. Press and hold to turn the unit OFF. Rotate to adjust the volume. -
Page 8: Remote Control Overview
Remote control overview Front view 1. Change Current Source. 2. Eject the disc. 3. Enter the DVD menu. EJECT 4. Enter the DVD Title. 5. Zoom in /out on an image. 6. Select radio band. 7. EQ setting 8. Dimmer adjustment 9. -
Page 9: Back View
Remote control overview Back view Notes on Remote Control Usage 1. Aim the remote control at the remote sensor on the unit. 2. Replace the battery from the remote control or insert a battery insulator if the battery has not been used for a month or longer. -
Page 10: Basic Operations
Basic Operations Detect parking brake • Connect the cable "BRAKE" to the parking brake switch to view video files on the TFT monitor. Engage the parking brake for viewing videos. • When the parking brake is not engaged, the monitor displays "Warning!!!, Video playback is disabled for your safety. -
Page 11: Eq Menu
Basic Operations EQ menu The Audio Control feature allows you to easily adjust your audio system to meet the acoustical characteristics of your vehicle, which vary depending on the type of vehicle and its measurements. Proper setting of the Fader and Balance boosts the effects of the cabin equalizer. Select preset equalizer 1. -
Page 12: Setting Date /Time
Setting Date /Time Date /Time 1. Touch [ 2. Touch [ Time ]. The date/time setup menu is displayed. Date 1. Touch [ Date ]. 2. Touch the date information on the screen . A submenu is displayed. 3. Touch [ ] or [ ] to set year, month and day. -
Page 13: Radio Mode
Radio Mode Tuner TFT display 1. Touch to view the SOURCE MENU and select a new playback source 2. AF: Alternative Frequency indicator 3. TA: Traffic Announcement indicator 4. Distant signal broadcasting indicator 5. Current radio band indicator 6. Clock 7. -
Page 14: Preset Station
Radio Mode Preset station The unit has 5 bands, such as FM1, FM2, FM3, AM1, AM2, and each band can store 6 stations; the unit can store 30 stations in total. Intro/Scan Press the [ ] icon to intro. Each stored station will play for 5 seconds automatically. -
Page 15: Rds ( Radio Data System )
Radio Mode RDS ( Radio Data System ) The unit provides basic functions of RDS. RDS service availability varies with areas. Please verify if RDS service is available in your area. AF function Alternative Frequencies Lists are used in conjunction with the PI code (Program Identification code)to assist automatic tuning. -
Page 16: Playback Mode
Playback Mode Load a disc You can play video, audio or images stored on the following discs: • DVD Video, DVD-R, DVD-RW • VCD • Audio CD, CD-R, CD-RW Note: Ensure that the disc contains playable content. Eject a disc Press the [ ] key on the front panel to eject the disc. -
Page 17: Search For A Folder
Playback Mode Search for a folder For Audio Files 1. Touch [ ] to display all available audio folders. 2. Touch a folder,then touch the desired file. 3. Touch the file again to start play. For Video Files 1. Touch [ ] to display all available video folders. -
Page 18: Repeat A-B
Playback Mode For CD/MP3/WMA files: 1. Touch anywhere except the upper left corner to display menu on the screen. 2. Touch [ ] repeatedly: ] Repeat single: Play the current single repeatedly. ] Repeat all: Play all in the all repeatedly. ] Repeat off: Cancel repeat play. -
Page 19: Playback Information
Playback Mode Playback information Touch the screen when playing back DVD and VCD discs and the playback information will be displayed on the top area of the TFT. For DVD 1. Disc type. DVD T:01/08 C:005/012 2. DVD Title information. “01/08” indicates that this DVD has 8 titles and the title playing back now is the first title. -
Page 20: Bluetooth Mode
Bluetooth Mode You can make or receive phone calls with Bluetooth-enabled phones through the unit. You can also listen to music from a Bluetooth-enabled device. Pair the Bluetooth-enabled devices To connect your Bluetooth device to the unit, you need to pair the device to the unit. -
Page 21: Adjust Bluetooth Settings
Bluetooth Mode Incoming call By default, all incoming calls are received automaticaly. 1. If there is an incoming call, the screen will appear “Incoming”. 2. You may touch the screen to select [ hang up ] or [ Answer ]. •... -
Page 22: Incoming Call
Bluetooth Mode Bluetooth music mode A2DP A2DP is short for Advanced Audio Distribution Profile. The mobile phones supporting this function can transmit stereo audio, whereas the ones not supporting this function can transmit mono audio only. AVRCP AVRCP is short for Audio/Video Remote Control Profile. The mobile phones supporting this function can control the playback of a Bluetooth audio player. -
Page 23: Settings
Settings General 1. Touch [ General ] in the settings page. 2. Touch to highlight a setting. 3. Touch on the option to display/select an option. 4. Touch [ Setting ] or press the Menu button on the front panel to exit. General settings Options Description... -
Page 24: Sound
Settings Sound 1. Touch [Sound]. 2. Touch an option repeatedly to select. Sound settings Options Description Flat 80Hz Sub Woofer Touch to select a crossover frequency. Filter 120Hz 160Hz When listening to music at low volumes, this feature will selectively boost Loud On/Off certain bass and treble frequencies. -
Page 25: Dvd
Settings 1. Touch [Disc]. 2. Touch an option repeatedly to select. DVD rating Options Description Set password Set password to restrict the play of discs. The default password is 0000. Kid safe Acceptable for children. Acceptable for general viewers. Parental guidance suggested. PG-13 Unsuitable for children under age 13. -
Page 26: Informations
When the unit hangs up, you can reset it. Press [ RESET ] with a ball-point pen or similar tool. Reset Reset Reset M-OF7030 M-OF7050 M-OF7040 Tip: When the unit has been reset, all the settings will return to default settings. - Page 27 Station Seeking Level ....................... 20~28dBμV Distortion ..........................≤1.0% Stereo Separation (1KHz) ......................≥25dB Antenna Impedance ........................75Ω Residual Noise Sensitivity (S/N=20dB) ..................30dBμV Selectivity (±9KHz) ........................≥50dB M-OF7030 LCD Screen size ..........................6.2 inches Display resolution ......................800X480dots Contrast ratio ..........................400 M-OF7040 LCD Screen size ..........................8 inches Display resolution ......................
-
Page 28: Specifications
Specifications Supported formats: • USB or memory file format: FAT16, FAT32 • Mp3 bit rate(date rate): 32-320 Kbps and variable bit rate • WMA v9 or earlier • Directory nesting up to a maximum of 8 levels • Number of albums/folders: maximum 99 •... - Page 29 M-OF7030 Wire connections YELLOW VIDEO OUT WHITE USB/ AUX IN YELLOW BLACK WHITE WHITE BLUE SUB OUT YELLOW REAR CAMERA BLACK - 28 - DOP User manual_ENG.indd 28 14/11/2013 12:05:16...
-
