Rangevision Smart Quick Start Up Manual page 2

1. Basic information
RangeVision Smart three-dimensional
stationary objects through a contactless method. Hardware part of this system
is the RangeVision Smart scanner, mounted on a tripod and connected to
a stationary computer or a laptop; software part is represented by RangeVision
ScanCenter and ScanMerge. The principle of the operation of the scanner is based on
the structured light technology.
In order to maintain high accuracy when scanning items, as well as when changing
a scanning zone, provided software allows you to fully calibrate the scanner.
2. Conditions of use and transport
The scanner can be operated at a constant ambient temperature from 5 to 30 degrees
Celsius. The maximum air humidity is 80 %. The calibration plate must be transported
in special travel case supplied.
Please do not use in direct sunlight. To achieve best results please use in controlled
environment.
You may not use the equipment in a dusty or smoky environment.
3. Technical specifications
Scanning zone number
Size of Scanning Zone (W x H x D), (mm)
3D resolution:
Average scanning time (depends on your computer) ~ 7 seconds (lighting)
+ 5 seconds (model calculation)
Resolution of cameras - 1,3 Mpix. (1280x1024))
The format of the data on the output
Source of light
Scanning principle
Weight of the scanning module
Operating system
Power supply
Calibration time
scanner is designed for digitizing
[ 1 ] [ 2 ] [ 3 ]
500 × 375 × 375 300 × 225 × 225 133 × 100 × 100
0,4 mm 0,24 mm 0,12 mm
.STL
LED-projector
Structured light
1 kg
Windows XP SP2, Windows 7 32bit, 64bit.
220V, 100W
7 minutes
4. Equipment set
name
Scanning module consisting of:
Camera
Multimedia projector
1
Mounting construction
2x USB / 1x HDMI cable wrapped together
AC Adapter
Disk with software:
- RangeVision ScanCenter scanning software
2 - RangeVision ScanMerge processing software
- User manual
- Drivers
3 License key (USB stick)
4 Tripod
5 Magnetic stand for calibration plates
6 Small calibration plate for zone 3
7 Large calibration plate for zone 1 / 2 (behind protective foam)
8 Scanning markers (behind protective foam)
9 Allen key – to adjust position of the cameras
10 Travel case
q-ty
1
2
1
1
1
1
0
online
online
online
online
1
1
1
1
1
1
1
1
