- Page 1 G O A H E A D A N D O V E R S L E E P. N E E D A H A N D ? Contact us at service@bludot.com or Graceful lines meet gorgeous wood. 844.425.8368 for assistance.
-
Page 2: Parts & Hardware
8051 Parts & Hardware Woodrow Half Moon Connector Pt. 8050 Pt. 8051 Pt. 2007 Pt. 1685 Pt. 1686 Pt. 9029 Pt. 9028 Pt. 1213 Center Leg Side Rail Center Rail Mattress Slat Headboard Footboard *Assembly and part quantities will differ for Twin sized bed. See note on steps 4,5, 6, and 7 for details. 1 | 8 4 4 . - Page 3 Step 01 I N S TA L L I N G C O N N E C T O R B O LT S . Attach the provided hardware as shown on headboard and footboard. PT. 80 50 x 8 A S S E M B LY N O T E S S E R V I C E @ B L U D O T.
- Page 4 Step 02 A S S E M B L E S I D E R A I L S T O H E A D B O A R D. Align side rails with headboard as shown. Have a second person help align parts to prevent damage.
- Page 5 Step 03 S E C U R E S I D E R A I L S T O H E A D B O A R D. Secure side rails with headboard as shown using the hardware provided. 8051 Woodrow Half Moon Connector PT.
- Page 6 Step 04 A S S E M B L E S I D E R A I L S T O F O O T B O A R D. Align side rails with footboard as shown. Have a second person help align parts to prevent damage.
- Page 7 Step 05 S E C U R E S I D E R A I L S T O F O O T B O A R D. Secure side rails with footboard as shown using the hardware provided. 8051 Woodrow Half Moon Connector PT.
- Page 8 Step 06 A S S E M B L E C E N T E R R A I L . Attach the center legs to the center rail as shown using the provided hardware. NOTE: This step may be skipped for Twin sized bed assembly.
- Page 9 Step 07 AT TA C H C E N T E R R A I L . Place center rail in corresponding slots in headboard and footboard. Ensure that the pre-drilled holes are aligned and secure center rail in place using the provided fasteners as shown.
- Page 10 Step 08 A S S E M B L E M AT T R E S S S L AT S . Align mattress slats with blocks on side rails as shown. NOTE: Twin sized bed will only contain one mattress slat.
- Page 11 Step 09 S E C U R E M AT T R E S S S L AT S . Attach the mattress slats to the center rail and side rails as shown using the provided hardware. NOTE: Twin sized bed will only require four bolts to secure slat in place.
-
Page 12: Additional Information
Additional Information CLE A N Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use a quality cleaner formulated for wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain. 11 | 8 4 4 . 4 2 5 . 8 3 6 8 W O O D R O W B E D C O L L E C T I O N...
