7.2.1 DISASSEMBLING THE SINGLE-CHANNEL PIPETTE UP TO 1ml
1. Unscrew the coupler and remove p
cone.
2. Remove the lower part and pull out
the piston and other parts from
p cone.
- Remember to keep all parts in order
for reassembly.
- Clean the piston, the piston spring,
seal and the o-ring with isopropanol
and lint free ssue. Allow them to
dry.
- Check the
ar cles and remove, if any. Grease the
cleaned parts with the approved
lubricant provided with each pipe e.
7.2.2 DISASSEMBLING THE SINGLE-CHANNEL PIPETTE: 5 - 10ml
1. As per earlier process remove the
ejector by pulling it a er pressing
the p ejector pusher completely down.
2. Unscrew the coupler to
pull out the piston and other parts from
p cone.
- Remember to keep all parts in order for
reassembly.
- Clean the piston, the piston spring, seal
and the o-ring with isopropanol and lint
free ssue. Allow them to dry.
- Check the p cone for foreign par cles
and remove, if any. Grease the cleaned
parts with the approved lubricant
provided with each pipe e.
7.3 ASSEMBLING THE PIPETTE
7.3.1 ASSEMBLING THE SINGLE-CHANNEL PIPETTE UP TO 1ml
1. Carefully insert the piston into the p cone.
2. Press on piston from above and check for free movement.
The piston must be able to move freely without resistance.
3. Reconnect the p cone to the main body by screwing into the
threaded sec on.
4. Reinstall the p ejec on collar.
7.3.2 ASSEMBLING THE SINGLE-CHANNEL PIPETTE: 5 - 10ml
1. Insert the seal on posi on.
2. Keep retainer on piston and spring. Press the spring to fit
with piston.
3. Carefully insert the piston into the p cone.
4. Press on piston from above and check for free movement.
The piston must be able to move freely without resistance.
5. The coupler screw to p cone and screw with body.
6. Fit the ejector collar.
p cone for foreign
p cone and
