Display and Operation
Manual operation
The following operation modes will be activated through repeated pressing of the
level button:
-
Level 0 = MIN = Minimum
-
Level 1 = MID = Medium
-
Level 2 = MAX = Maximum
The active level is activated after 3 seconds. This prevents unnecessary switching
when setting the device. The level-indication and buttons light up in blue.
The device is equipped with proximity detection. When approaching a distance of
approx. 10 cm, the luminosity of the LED increases. After 30 seconds without
interaction, the LEDs dim down again and thus save energy.
Doc: 70-00-0842A V2.5, 20230220
Subject to alternation
© Vector Controls GmbH, Switzerland
www.vectorcontrols.com
MZ3-FU-V01
Level LEDs
Level button
Page 4-6
