Summary of Contents for Xiaomi Mi Robot Vacuum S10+
- Page 1 Robot Vacuum S10+ User Manual...
-
Page 2: Safety Information
Safety Information Read this manual carefully before use, and retain it for future reference. Usage Restrictions This product is for floor cleaning in a home environment only. Do not use it outdoors, on non-floor • surfaces, or in a commercial or industrial setting. This appliance can be used by children aged from 8 years and above and persons with reduced physical, •... - Page 3 cover, cover, or bumper as a handle. Do not use the robot vacuum at an ambient temperature above 40°C or below 0°C or on a floor with liquids • or sticky substances. Do not install, charge, or use this robot vacuum outdoors, in bathrooms, or near a pool. •...
-
Page 4: Batteries And Charging
Make sure the robot vacuum is turned off when being transported and kept in its original packaging if • possible. Please use this product in accordance with the instructions in the user manual. Users are responsible for • any loss or damage arising from improper use of this product. Batteries and Charging WARNINGS: Do not use any third-party battery, power cord, or charging dock. -
Page 5: Eu Declaration Of Conformity
accordance with local laws and regulations of the country or region it is used in. When removing the batteries from the product, it is better to use up the batteries and make sure your • product is disconnected from power. 1). -
Page 6: Product Overview
Product Overview Accessories Pre-installed Accessories Brush Brush Cover Dust Compartment Water Tank Other Accessories Side Brush Cleaning Tool Power Cord Robot Vacuum Note: Illustrations of product, accessories, and user interface in the user manual are for reference purposes Mop Pad × 2 Mop Pad Holder ×... - Page 7 Robot Vacuum Power/Clean Button Power on/off: Press and hold for 3 seconds Clean: Press to start cleaning after the robot vacuum is powered on Dock Button Press to send robot vacuum back to charging dock Enable/Disable child lock function: Press and hold for 3 seconds Indicator White: Cleaning/Cleanup completed/Fully charged •...
- Page 8 Robot Vacuum and Sensors Cliff Sensor Omnidirectional Wheel LDS Laser Sensor Cover Side Brush LDS Laser Sensor Charging Contacts Bumper Brush Brush Cover Brush Cover Clip Main Wheel Main Wheel Line Laser Sensor Mop Pad Holder Mounting Hole Cover Reset Button Press and hold for 3 seconds to restore factory settings Wi-Fi Indicator Dust Compartment...
-
Page 9: Charging Dock
Charging Dock Water Tank Water Filling Opening Water Tank Plug Signaling Area Charging Contacts Water Tank Release Button Power Port Dust Compartment Mop Assembly Mop Pad Attachment Area Dust Compartment Clip Dust Compartment Cover Clip Filter Dust Compartment Cover Filter Clip Mop Pad Holder Mop Pad... -
Page 10: How To Install
How to Install Remove Protective Coverings Connect to An Electrical Outlet Before using the robot vacuum, remove the protective strips from both sides. Place the charging dock near an electrical outlet in an area with a good Wi-Fi signal. Then connect the charging dock to power. Install the Side Brush Note: Do not place any items within the range of 0.5 m at either side or within 1.5 m in front of the... -
Page 11: How To Use
Notes: · This robot vacuum works with the Mi Home/Xiaomi Home app, and it supports Android 4.4 & iOS 10.0 or above. Method 2: Tap the button in the app to start cleaning. - Page 12 Use the Vacuuming & Mopping Function 1. First dampen the mop pad and wring out excess water. 3. Press the button on the robot vacuum or use the app to make the robot Next, install and attach the mop pad onto the mop pad holder in place. vacuum perform the vacuuming and mopping task.
-
Page 13: Update The Firmware
Resume Cleanup Update the Firmware If the robot vacuum starts running low on battery during a cleaning task, it will You can update the firmware via the app. Before updating, make sure the robot automatically return to the charging dock to recharge, then resume cleanup vacuum is on the charging dock and has at least 15% battery left. -
Page 14: Care And Maintenance
Care & Maintenance Sensors and Charging Contacts Brush * It is recommended to clean every month. * It is recommended to clean every two weeks. Use a soft cloth to clean all sensors and charging contacts in the robot vacuum: 1. - Page 15 Side Brush Dust Compartment * It is recommended to clean every two weeks. * It is recommended to clean every week. 1. Flip the robot vacuum over and remove the side brush upwards to clean it. 1. Open the cover of the robot vacuum, and press the dust compartment clip to 2.
- Page 16 Filter * It is recommended to clean every two weeks. 1. Remove the filter from the filter clip as illustrated. 3. Open the dust compartment cover, fill the dust compartment with clean water and close the dust compartment cover. Shake the dust compartment from side to side and then pour the dirty water out of the compartment.
- Page 17 Mop Pad Charging Dock * After-each-use cleaning is recommended. * Clean it as needed. 1. Remove the mop pad from its holder. Clean the charging contacts and the signaling area of the charging dock with a soft, dry cloth. 2. Clean and dry the mop pad. Battery The robot vacuum contains a high-performance lithium-ion battery pack.
-
Page 18: Troubleshooting
Troubleshooting Issue Possible Cause and Solution The battery level is low. Fully charge the robot vacuum, and then try again. The robot vacuum does not turn on. The ambient temperature is lower than 0°C or higher than 40°C. Make sure to use the robot vacuum between 0°C and 40°C. - Page 19 Issue Possible Cause and Solution Check whether the battery level is sufficient. The robot vacuum needs to have a battery level of 15% or more to The robot vacuum does not carry out the scheduled cleanup. start a scheduled cleanup. Check whether the water in the water tank is sufficient.
-
Page 20: Specifications
Specifications Robot Vacuum Charging Dock Name Robotic Vacuum Cleaner Model CDZ2101 Model B105 Item Dimensions 130 × 126 × 93 mm Item Dimensions 350 × 350 × 97 mm Rated Input 100–240 V ~ 50/60 Hz 0.5 A Battery 4800 mAh (Rated Capacity) Rated Output 19.8 V Charging Time... - Page 21 • For further information, please go to www.mi.com Manufactured for: Xiaomi Communications Co., Ltd. • Manufactured by: Dreame (Tianjin) Information Technology Co., Ltd. (a Mi Ecosystem company) • Address: Room 2112-1-1, South District, Finance and Trade Center, No.6975 Yazhou Road, Dongjiang Bonded Port Area, Tianjin Pilot...
