MERLIN STEALTH MASTER
In order to facilitate the installation process, and cater from simple to extremely complex
perimeter security requirements, Nemtek offers a range
of products that can be combined to provide an integrated security solution.
This also enables integration into other security systems such as access control and CCTV
systems.
The currently available building blocks are:
Energizer/Controller Related
• Merlin M1XS and M2XS range of energizers. The fundamental building block of an
electric fence. No special software is required when changing from a single energizer
system to a networked system with multiple energizers. The same generic building
block is used.
• Merlin Master M25S and Master M28S. Used for networking up to ten energizers M2XS
energizers. Keypad located at master gives fence indication of twenty zones. Global
and specific commands can be issued from this keypad. Slaves may use individual
keypads as well.
• Merlin embedded linux controller platform. This provides total accessibility to
individual or networked energizers. Permits energizers to become part of a local area
network or to be accessed remotely. A range of communication protocols have been
incorporated to provide flexibility / security and connectivity. Visit www.nemtek.com
for more information and contact details.
Communication Related
• Merlin Stealth RS485/RS232 converter board.
• Merlin Stealth Fiber-Optic/RS485/RS232 converter board.
The remainder of this document discusses the installation of the Merlin M25 and M28 Stealth
Master energizers in conjunction with standard Merlin Stealth Energizers. However, the
networking principals remain the same. An installation using a Master controller can easily be
upgraded to an embedded Linux platform controller.
Introduction
4
