Maximum Setpoint
300°F
This reference guide covers standard
Advantage temperature control units with the
T300 Series Control Instrument. This guide
may be used for customized units using the
T300 Series Control Instrument even when
the unit may not be physically the same as the
units depicted in the included photos.
Before Installing or Operating
1. This unit is designed to be used with water as the circulating fluid. The quality of fluid used in
your temperature control unit will greatly effect its short and long-term operation. Lack of as
well as improper water treatment can damage the temperature control unit by causing scale
build-up, excessive corrosion and/or bacterial contamination. It is the equipment owner's
responsibility to prevent damage caused by poor water quality. The services of a water
treatment professional is recommended.
2. Before installing and operating the unit, be aware of and follow any local laws and codes that
apply to the installation.
3. When contacting the Service Department always have the unit Model and Serial number from
the data tag located on the side of the unit.
Installation
Electrical: Be certain all electrical connections are tight in the unit. Install unit power cord (when
1.
supplied) to power disconnect switch. Applied power must be equal to the unit voltage and amps
listed on the unit data tag. Follow all applicable local and national electrical codes.
Plumbing: Care should be taken to use materials (hose, rigid piping, valves or filters) rated
2.
for the temperature and pressure duty of your unit. Most units have a maximum operating
temperature of 300°F or less and a maximum pressure of 150 PSI. The unit is most efficient
when full size plumbing is run from the unit connections to and from the process. If necessary,
reduce the plumbing size at your process, not at the unit.
Sentra SR Series with T300 Control Instrument
INSTALLATION • OPERATION • TROUBLESHOOTING
*
SERVICE DEPARTMENT: 317-887-0729
*Reference the manual for requirements for 300°F set point.
REFERENCE GUIDE
Download and read the manual before starting installation.
The complete manual is available online at
www.advantageengineering.com/Sentra-SRT-300.
Refer to the Manual for complete details on Installation.
