displayit.com
800.207.0311
Parts List
8 - Frame Perimeter Pieces
(See Diagram 1 for details)
4 - Flat Connecting Plates with Wing Nuts
4 - Corner Connecting Plates with Wing Nuts
4 - Extra Wing Nuts
(1/4-20 Thread Size)
1 - Vertical Support Set
(Set includes two poles and a plastic lock tube)
1 - Flare Spacing Ruler
3 - Double-Sided Curtain Lights
3 - Power Supplies (100 Watts)
16 - Light Mount Clips*
1 - 10 Foot Power Cord with 5 Quick-Connects
4 - Wire Management Clips
2 - Flare Feet
6 - T-Bolts for Flare Feet*
6 - Washer Wing Nuts for Flare Feet*
(1/4-20 Thread Size)
After-Hours Emergency: Call or Text 678.723.5343
8' (92" x 92") Flare
Assembly Instructions Page 1
* Includes extras provided
Need Help?
Scan the QR code or go to
displayit.com/flare-guide
to watch an assembly video.
Flare v2.0 Updated 11/22/2016
Advertisement
Table of Contents
Related Manuals for displayit Flare
Summary of Contents for displayit Flare
- Page 1 1 - 10 Foot Power Cord with 5 Quick-Connects 4 - Wire Management Clips 2 - Flare Feet 6 - T-Bolts for Flare Feet* 6 - Washer Wing Nuts for Flare Feet* (1/4-20 Thread Size) * Includes extras provided displayit.com 800.207.0311...
- Page 2 8’ (92” x 92”) Flare Assembly Instructions Page 2 1. Upack the frame. Save all foam pieces for repacking later. Lay out the frame pieces as seen in Diagram 1. Frame perimeter pieces are labeled with stickers matching Diagram 1 to make this step easier.
- Page 3 8’ (92” x 92”) Flare Assembly Instructions Page 3 Press Lock Tube Slide Lock Tube 4. Unroll the included spacing ruler and 5. Install the suport pole as noted on the ruler (Diagram 2). place it on the ground inside the frame.
- Page 4 8’ (92” x 92”) Flare Assembly Instructions Page 4 7. Attach the power supplies to the frame via the velcro strips and connect the wires to the curtain lights. 7. To help stop wire shadows on the graphic, use 6. Run the main power cables through the wire the provided snap-on wire management clips.
- Page 5 8’ (92” x 92”) Flare Assembly Instructions Page 5 Graphic Installation Caution! Installing silicone-edged graphics is techniqe sensitive; Practice will shorten installation time. Handle graphics with care with clean hands in a clean environment. Cloth or latex gloves recommended. Keep graphics away from sharp objects.
- Page 6 8’ (92” x 92”) Flare Assembly Instructions Page 6 Packing Instructions Failure to follow packing instructions may result in damaged items. Bottom Layer Top Layer Frame perimeter metal pieces with foam between Fabric Graphics Short foam on ends Wires &...
