displayit flare Assembly Instructions

M8 Threaded
Socket
ACCESSORY
KIOSK
SIDE
TOP
Side Top Vertical x2
M8 Threaded
Sockets
Inline Splice x2
Back Edge
Top Plate x1
Large Panel x1
Flare Frame Required
For Support
displayit.com
Parts List
Parts are not shown to scale
ACCESSORY
KIOSK
SIDE
BOTTOM
Adjustable
Foot
Side Bottom Vertical x2
1/4-20 x 1" Thread
.5" x .7" Oval Head
Thumb Knob x4*
Rubber Pads
M8 Knob
Lock
Shelf Bracket
with Knob Lock x2
Small Panel x2
*Extra parts are provided
800.207.0311 After-Hours Emergency: Call or Text 678.723.5343
Accessory Kiosk with Monitor Mount
Assembly Instructions Page 1
ACCESSORY
KIOSK
STANDARD
HORIZONTAL
M8 Knob Lock
Standard Horizontal
with Knob Locks x3
1/4-20 Thread
Thumb Nut x8*
32" x 11" Shelf
Shelf x1
Phillips Head
1/4-20 x 2.5"
Thread
2.5" Screw and Washer x4*
ACCESSORY
KIOSK
MONITOR
HORIZONTAL
Drill Holes
M8 Knob
Lock
Monitor Horizontal
with Knob Locks x2
M8 x 24mm
Thread
M8 Knob x18*
(Includes 10 pre-installed in horizontals
and 2 pre-installed in shelf brackets)
Monitor Mount x1
CableClips x4
Updated 11/15/2019
