Install grille.
10
1
Connect plug from grille to
wire panel. Squeeze grille
springs and insert into slots in
blower. Push grille up against
ceiling.
Install wall control.
1 11
Note: Location of wall control must be within
20-feet (not obstructed) of grille.
Use one of two methods to attach control:
(1) Mount control to new single-gang
electrical box. (Recommended method)
(2) Mount control to wall with clearance hole
in wall.
Note: When replacing an existing switch with the
new wireless wall control, care must be taken
to properly terminate the existing wiring in a
method approved by local building codes. If
you are unsure, contact a qualifi ed person.
Remove control module, install 2-AAA batteries,
and replace module.
Snap control cover in place. Note: Metallic cover
plates are not recommended.
Pair wall control.
12
1
To pair the wall control, turn on power to the fan and
(within 3 minutes) press and hold the white light
button icon on wall control for at least 5 seconds.
The light on the fan will fl ash when paired.
• If installing more than 1 Sensonic fan in your house,
only the fan that you are attempting to pair with a wall
control should be powered. All other Sensonic fans
in your house should not be powered to prevent the
wall control from pairing to multiple fans.
Establish Bluetooth
13
1
with your device.
Connect to "ChromaComfort-Sensonic Speaker"
in your phone's Bluetooth
music from your favorite app. When prompted,
use PIN 1234 to connect.
Apple, and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries and regions.
App Store is a service mark of Apple Inc. Google Play and the Google Play logo are trademarks of Google LLC.
®
connection
®
settings to stream
Note orientation of tab
and buttons.
For more functions and custom
14
1
options.
Download the ChromaComfort
Apple App Store or on Google Play.
Enjoy your ChromaComfort
Scan to install
ChromaComfort™
4
1
2
TM
app from the
TM
experience!
Scan to access quick
start guide
app.
If grille spring
becomes dislodged
from grille - snap it
back into place as
shown.
WHITE
LIGHT
BUTTON
Scan to see how to use
ChromaComfort™
app.
1103974C
