Page 1: Specifications
AX Series Security and Communication System Architectural and Engineering Specifications Aiphone AX Series 13710 (28 13 00) - 1... - Page 2 Aiphone AX Series 13710 (28 13 00) - 2...
- Page 3 Delete version not required. SECURITY AND COMMUNICATION SYSTEM Specifier Notes: This section covers Aiphone Corporation “AX Series” integrated security and communication system. Consult Aiphone Corporation for assistance in editing this section for the specific application. PART 1 GENERAL SECTION INCLUDES Integrated security and communication system.
-
Page 4: System Description
ISO 9001:2000 – Quality Management Systems – Requirements. TIA/EIA 568 – Commercial Building Telecommunications Cabling Standard. SYSTEM DESCRIPTION Specifier Notes: Edit the system description as required for the project. Consult Aiphone Corporation for more information. Components: Door stations. - Page 5 LED for individual door station flashes (double-flash for priority call). At same time, telephone call is placed to programmed CO line number. Aiphone AX Series 13710 (28 13 00) - 5...
- Page 6 If you press down ALL CALL button but do not start talking within 30 seconds, system goes back to standby mode. You can also return to standby by pressing OFF button. Aiphone AX Series 13710 (28 13 00) - 6...
- Page 7 Calls have priority based on the time the call was initiated. (Earlier call has priority over later call). Communication Priority, from Highest to Lowest: Door station, telephone line communication. Priority All Call. Door station to master station communication. Aiphone AX Series 13710 (28 13 00) - 7...
-
Page 8: Quality Assurance
Warranty Period: Two years from date of Substantial Completion. PART 2 PRODUCTS MANUFACTURER Aiphone Corporation, 1700 130th Avenue NE, Bellevue, Washington 98005. Toll Free (800) 692-0200. Phone (425) 455-0510. Fax (425) 455-0071. Website www.aiphone.com. E-mail info@aiphone.com. SECURITY AND COMMUNICATION SYSTEM... - Page 9 Integrated Security and Communication System: Aiphone “AX Series”. Power Source: 24 V DC, 2 A. Two PS-2420UL (110 V AC) per video system. One PS-2420UL (110 V AC) per audio system. Door Station Calling: Tremolo call tone programmable from 10 to 600 seconds or infinite.
- Page 10 Allows paging to external speakers from a door station zone on CEU. For each zone of paging, use one paging adaptor with appropriate sized amplifier. Provides outgoing paging only. Specifier Notes: Specify the following add-on exchange unit if required. Aiphone AX Series 13710 (28 13 00) - 10...
- Page 11 Receive Switch: Low, medium, high. Transmit Switch: Low, medium, high. Call tone. LCD brightness control. Jacks: Headset receiver. Headset microphone. Headset Volume Controls: Receiver. Microphone. Directory Cards and Covers: Master station. Door station. Reset switch. Aiphone AX Series 13710 (28 13 00) - 11...
- Page 12 Operating Temperature: 14 degrees F to 140 degrees F (minus 10 degrees C to 60 degrees C). Fixed Color Video Door Station: Model AX-DV. Faceplate: Aluminum die cast. Surface mount. Call Button: Metal. Aiphone AX Series 13710 (28 13 00) - 12...
- Page 13 Fixed Color Video Door Station: Model AX-DVF-P. Proximity Card Reader: Embedded “HID ProxPoint Plus”. Faceplate: Stainless steel. Specifier Notes: Specify flush or surface mount. [Flush mount] [Surface mount by adding SBX-DVF-P]. Call Button: Metal. Camera. Aiphone AX Series 13710 (28 13 00) - 13...
- Page 14 Call Button: Red mushroom. Specifier Notes: Specify flush or surface mount. [Flush mount in standard 2-gang box] [Surface mount by adding SBX-2G]. Accessory Station: Model HID-SS. Card Reader: Embedded “HID ProxPoint Plus”. Aiphone AX Series 13710 (28 13 00) - 14...
- Page 15 Call button. Interior Sub Station: Model AX-BN. Housing: ABS plastic. Semi-flush mount. Speaker. Microphone. Call button. Privacy button. PART 3 EXECUTION EXAMINATION Examine areas to receive integrated security and communication system. Aiphone AX Series 13710 (28 13 00) - 15...
-
Page 16: Installation
Staples: Do not use staples that crimp cables tightly. Do not use T-18 and T-25 cable staples. Use firestop cables that penetrate firewalls. Use plenum-rated cables where mandated. ADJUSTING Aiphone AX Series 13710 (28 13 00) - 16... - Page 17 Provide instruction and training by qualified representative of manufacturer. PROTECTION Protect installed integrated security and communication system from damage during construction. Aiphone AX Series END OF SECTION 13710 (28 13 00) - 17...
