- Page 1 MUL-325 Tensioner for POLYESTER Operation Manual Strap Type Composite/Woven Cord Strap Width Up to 3/4" (19 mm) Strap Thickness All existing straps Joint Type Buckle Weight 3.6 lbs (1.6 kg) Footprint L: 4.75"; W: 2.75" Handle Length 9"...
- Page 2 End 100 into Buckle 102. Manually, take out the excess strap by pulling on End 100. Place the ” from the Buckle 102 as shown on Fig. 2. MUL-325 approximately Fig.2 2. Raise Gripper Foot 48 by pressing down on Tension Handle 04. Load Bottom Strap 101 under Cutter Housing 45, under Gripper Foot 48 end release Tension Handle 04.
- Page 3 3. Apply tension by ratcheting Tension Handle 04 as shown on Fig. 4. Fig. 4 4. Once satisfactory tension is achieved the strap is ready to be cut. Push down on the Tension Handle 04 until the strap is cut and slide the tensioner to the right to release the strap from under the Gripper Foot 48 as shown on Fig.
