- Page 1 SELF SUPPORTING LINER Installation Instructions Use and Care Information Instructions d'installation Utilisez et d'entretien Instrucciones de instalación Información de uso y cuidado LINSPT301228 LINSPT361228...
-
Page 2: Table Of Contents
CONTENTS Section Page Important Safety Instructions Liner Dimensions Parts Tools Needed Preparing For Installing The Liner Preparing The Cabinet Floor Installing The Liner Attaching The Front Trim Installing The Range Hood... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS BEFORE YOU START INSTALLING Refer to Faber U&C Guides for Installation Instructions for your range hood model. Pre-Planning Your Installation - Important: The recommended height to install this hood off the cooktop is a minimum of 24" over electric cooking surfaces and a maximum of 30”... -
Page 4: Liner Dimensions
LINER DIMENSIONS DRAFT 29-OCT-2020 22:36... -
Page 5: Parts
TOOLS NEEDED TOOL Tape Measure Pencil Phillips Screwdriver Metal sheers Work gloves PARTS PARTS INCLUDED REF. PART Bottom lip of the metal liner Front trim of the metal liner REF PART Pozi Screws (1/8" x 5/8") -
Page 6: Preparing For Installing The Liner
PREPARING FOR INSTALLING THE LINER INSPECT THE RANGE HOOD AND THE LINER: Fully inspect the range hood and the liner for damage before installation. If there is damage please document and contact your retailer. IF DAMAGED BY THE CUSTOMER, REPAIR OR REPLACEMENT IS THE RESPONSIBILITY OF THE CUSTOMER. -
Page 7: Preparing The Cabinet Floor
Model Without With back Width Width (x) Width Depth back panel panel * LINSPT301228 30 inches '' - 20 '' - 20 '' - 20 LINSPT361228 36 inches '' - 20 * Assumes back panel cabinet thickness of 3/8 "... -
Page 8: Installing The Liner
INSTALLING THE LINER ALIGN THE LINER WITH THE CABINET FLOOR: Align the bottom lip of the rear liner with the bottom lip of the cabinet. ATTACHING THE LINER: Attach the back of the liner with 9 screws. 3 screws along the back, 3 on each side. -
Page 9: Attaching The Front Trim
ATTACHING THE FRONT TRIM Align the front trim to the installed portion of the liner. Use the guide hole to locate the correct depth for the application. Attach the front trim with 2 screws on each side of the trim. -
Page 10: Installing The Range Hood
Attach the front trim with 3 screws. INSTALLING THE RANGE HOOD Follow the Installation Instructions for your range hood to install the range hood to the liner. NOTE: Inca Lux and Inca In-Light models will not need additional saftey screws to secure the hood to the liner. For all inca model refer to the hood installation manuals to finalize installation. - Page 12 TABLE DES MATIÈRES Importantes consignes de sécurité Dimensions de la hotte Hauteur requise pour l’installation Pièces Outils requis Méthode de ventilation Préparation du montage de la hotte Installation du support mural Choisir la méthode de ventilation Installation de la ventilation : option 1 - canalisation vers l’arrière Installation de la ventilation : option 2 - ventilation vers le haut Installation de la ventilation : option 3 - avec recyclage sans canalisation Installation du panneau...
- Page 13 IMPORTANTES CONSIGNES DE SÉCURITÉ VEUILLEZ LIRE ET CONSERVER LA PRÉSENTE NOTICE AVANT DE COMMENCER L'INSTALLATION...
- Page 14 CONTENIDO Instrucciones de seguridad importantes Dimensiones de la campana extractora Requisitos de altura de instalación Piezas Herramientas necesarias Método de ventilación Preparación para montar la campana extractora Instalación del soporte de pared Elección del método de ventilación Conexión de la ventilación: opción 1 - conducto trasero Conexión de la ventilación: opción 2 - ventilación superior Conexión de la ventilación: opción 3 - recirculación sin conducto Instalación del panel de confort...
- Page 15 INSTRUCCIONES DE SEGURIDAD IMPORTANTES LEA Y GUARDE ESTAS INSTRUCCIONES ANTES DE COMENZAR A INSTALAR...
- Page 16 991.0603.636_01 - 200220 D00005944_00...
