LITHOS
INSTRUCTIONS MANUAL
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lithos and is the answer not in the manual?

Questions and answers

Related Manuals for Faber Lithos

Summary of Contents for Faber Lithos

  • Page 1 LITHOS INSTRUCTIONS MANUAL...

  • Page 2: Recommendations And Suggestions

    RECOMMENDATIONS AND SUGGESTIONS The Instructions for Use apply to several versions of this appliance. Accordingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or im- proper installation.
  • Page 3 CHARACTERISTICS 62.5 * Dimensions of the hood in ducting version. ** Dimensions of the hood in recycling version. Components Ref. Q.ty Product Components Hood Canopy, complete with: Controls, Light, Fan unit, Fil- ters Telescopic chimney, comprising: Upper chimney Lower chimney Reduction flange ø...

  • Page 4: Installation

    INSTALLATION Drilling the Wall 150 150 Mark the following on the wall: • a vertical line up to the ceiling or surface above the hood, at the centre of the area in which the hood itself is to be fitted; •...

  • Page 5: Recirculation Version Air Outlet

    Mounting the hood body • Remove the metal grease filters by turning the handles pro- vided. • Adjust the two screws Vr, on brackets 11a, to a minimum. • Hook the hood canopy onto the two brackets 11a. • From inside the hood canopy, adjust the screws Vr to set the Hood Canopy level.

  • Page 6: Electrical Connection

    ELECTRICAL CONNECTION • Connect the hood to the mains through a two-pole switch hav- ing a contact gap of at least 3 mm. • Remove the grease filters (see paragraph Maintenance) being sure that the connector of the feeding cable is correctly inserted in the socket placed on the side of the fan.

  • Page 7: Control Panel

    Control panel BUTTON FUNCTIONS T1 Speed Turns the Motor on at Speed one. Turns the Motor off. T2 Speed Turns the Motor on at Speed two. T3 Speed Fixed When pressed briefly, turns the Motor on at Speed three. Flashing Pressed for 2 Seconds.

  • Page 8: Maintenance

    MAINTENANCE Grease filters CLEANING METAL SELF- SUPPORTING GREASE FILTERS • The filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher. • Remove the filters one at a time by pushing them towards the back of the group and pulling down at the same time.
